凯斯零件查询(8455) - CASE IH ROUND BALER (STANDARD) (1/92-12/99) (3-06) - PICKUP ROTOR ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
342 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700126793
|
[1] |
SHAFT
|
IH
ROTOR WA
|
| 2. |
433-612
|
[16] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 280430
|
| 3. |
492-11038
|
[16] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 4. |
425-106
|
[16] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 5. |
700705612
|
[4] |
CAM FOLLOWER
|
L
BEARING - cam, follower Superseded by part number: 86536275
|
| 6. |
700108618
|
[4] |
ARM
|
L
CRANK WA
|
| 7. |
702700045
|
[4] |
LOCK NUT
|
L
1/2-20 SPIRALOCK
|
| 8. |
710392
|
[8] |
BEARING, ROLLER, CYL,27.33 mm ID x 47.09 mm OD x 25.4 mm
|
L
BEARING - cylindrical Superseded by part number: 84330047
|
| 9. |
61-636
|
[4] |
HEX SOC SCREW,3/8"-16 x 2 1/4"
|
CAS
3/8-16 x 2-1/4 HSHCS SPL Superseded by part number: 61-33836
|
| 10. |
232-5316
|
[40] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 11. |
700120390
|
[4] |
ANGLE BAR
|
IH
ANGLE WA
|
| 12. |
700709760
|
[36] |
TINE
|
L
TINE - double
|
| 13. |
432-1632
|
[8] |
COTTER PIN,1/4" x 2"
|
CAS
Pin, Split (Cotter), 1/4" x 2" Superseded by part number: 88182
|
| 14. |
700108622
|
[8] |
FLANGED BEARING
|
L
FLANGE - bearing
|
| 15. |
434-616
|
[36] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 RHSNB Superseded by part number: 80280503
|
