213-126
|
[1] |
ADJUSTABLE CLEVIS,3/8"-24 x 2 1/2"
|
CAS
CLEVIS, ADJUSTABLE, 3/8"-24 x 2 1/2" Superseded by part number: 86625043, 231-126
|
| . . |
232-5316
|
[36] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| . . |
434-616
|
[36] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 RHSNB Superseded by part number: 80280503
|
| . . |
663562R1
|
[4] |
FLANGE
|
IH
- bearing
|
| . . |
51292
|
[3] |
SPHERICAL BEARING,1.25" ID x 72 mm OD x 19 mm
|
IH
- spherical Superseded by part number: 84330041, 47508357
|
| . . |
57596
|
[1] |
BELT
|
L
V-BELT
|
| . . |
58107
|
[6] |
SPRING
|
IH
- compression
|
| . . |
586156R92
|
[2] |
BEARING, ROLLER, CYL,0.7505" ID x 47 mm OD x 0.8437, 0.53125"
|
IH
BEARING - cylindrical Superseded by part number: 76802
|
| . . |
617863R1
|
[4] |
FLANGED BEARING
|
IH
- bearing
|
| . . |
063586
|
[1] |
CLEVIS PIN
|
IH
3/8 x 1-1/8 CLEVIS PIN Superseded by part number: 9838826
|
| . . |
700100927
|
[6] |
HUB
|
L
|
| . . |
700108622
|
[8] |
FLANGED BEARING
|
L
FLANGE - bearing
|
| . . |
700114144
|
[15] |
GUARD
|
L
WRAPPER - tine
|
| . . |
700119161
|
[4] |
SWITCH
|
L
SENSOR "A"
|
| . . |
700125679
|
[1] |
HITCH PIN
|
IH
PIN - hitch
|
| . . |
700705612
|
[4] |
CAM FOLLOWER
|
L
BEARING - cam Superseded by part number: 86536275
|
| . . |
700707171
|
[1] |
CROSS
|
CAS
AND BEARING KIT Superseded by part number: 84004289
|
| . . |
700707322
|
[12] |
LATCH ASSY.
|
L
FASTENER
|
| . . |
700707354
|
[1] |
CONNECTION,ELECTRIC
|
IH
ACTUATOR
|
| . . |
700707821
|
[1] |
BELT
|
CAS
LACING KIT COMPLETE Superseded by part number: 9847138
|
| . . |
700708736
|
[1] |
SEAL KIT
|
CAS
KIT
|
| . . |
700708790
|
[1] |
KIT
|
IH
PUSH PIN AND SPRING Superseded by part number: 782083
|
| . . |
700709041
|
[2] |
CROSS
|
CAS
AND BEARING KIT Superseded by part number: 84004283
|
| . . |
700709140
|
[28] |
SELF-TAP SCREW,Pan HD, 5/16" - 18 x 3/4"
|
IH
5/16-18 x 3/4 CRTHTCTS
|
| . . |
700709760
|
[36] |
TINE
|
L
TINE - double
|
| . . |
700709996
|
[3] |
SWITCH
|
IH
ACTUATOR
|
| . . |
700709999
|
[6] |
BELT,177.00 mm W x 14287.5 mm L
|
CAS
177.00 mm W x 14287.5 mm
|
| . . |
700710206
|
[6] |
PIN,1.73mm OD x 180mm L
|
L
- lacing
|
| . . |
700710208
|
[5] |
ROTARY SWITCH
|
L
SWITCH - assembly
|
| . . |
700710211
|
[3] |
ACTUATOR
|
IH
|
| . . |
700710945
|
[4] |
CLUTCH PLATE,126.75mm ID x 203.2mm OD x 3.18mm Thk
|
L
DISC - clutch
|
| . . |
700711114
|
[1] |
SEAL KIT
|
L
SEAL KIT
|
| . . |
700713617
|
[4] |
BELT,177.00 mm W x 14287.50 mm L
|
L
|
| . . |
700715662
|
[6] |
SEAL KIT
|
CAS
O-RING AND SEAL REPAIR KIT Superseded by part number: 86508168
|
| . . |
710392
|
[8] |
BEARING, ROLLER, CYL,27.33 mm ID x 47.09 mm OD x 25.4 mm
|
L
BEARING - cylindrical Superseded by part number: 84330047
|
| . . |
8025637
|
[2] |
SWITCH
|
L
- sensor
|
| . . |
8050825
|
[14] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
- cylindrical Superseded by part number: F82059
|
| . . |
844050
|
[1] |
SEAL
|
L
|
| . . |
Q1443
|
[1] |
KEY,5/16" Sq x 1 1/2", Par
|
IH
5/16 x 5/16 x 1-1/2 KEY
|
| . . |
Q3914
|
[1] |
KEY,Gib, 1/4" Sq x 1 1/2"
|
IH
1/4 x 1-1/2 GIB KEY
|
| . . |
Q3947
|
[2] |
KEY,Gib, 3/8" Sq x 1 1/2"
|
IH
3/8 x 1-1/2 KEY - gib
|
| . . |
Q81
|
[2] |
KEY,Gib, 3/8" Sq x 1 3/4"
|
IH
3/8 x 1-3/4 KEY - gib
|
