纽荷兰零件查询(F3DFA613B E004) - ENGINE 504384986 - 84550912 W/O BRAKE (10.250.03[02]) - TURBOBLOWER PIPES (504386825) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
361 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504388953 | [1] | | TUBE |
| 2. | 504388892 | [1] | | TUBE |
| 3. | 16673635 | [6] | BOLT,Hex, M8 x 1.25 x 20mm, Full Thd | TOR Superseded by part number: 16978124 |
| 4. | 504352446 | [2] | | GASKET |
| 5. | 504352449 | [1] | | GASKET |
| 6. | 504352448 | [1] | | GASKET |
| 7. | 16586221 | [2] | SCREW,Hex, M8 x 16mm, Cl 8.8 | TOR |
| 8. | 18088492 | [4] | RETAINER COLLAR | TOR |
| 9. | 16586821 | [1] | | SCREW,Hex, M8 x 45mm, Cl 8.8 |
