纽荷兰零件查询(F3DFA613B E004) - ENGINE 504384986 - 84550912 W/O BRAKE (10.304.05) - OIL PUMP PIPING (500398547) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
649 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 99475585 | [1] | STRAINER ELEMENT | TOR |
| 2. | 16586225 | [2] | BOLT,M8 x 16mm | TOR |
| 3. | 70925919 | [1] | O-RING,-222, Cl 7, 1.484" ID x .139" Thk | CMID=37.69 X3,53 mm |
| 4. | 99475589 | [1] | RIGID TUBE | TOR |
| 5. | 500343518 | [1] | GASKET | TOR |
| 6. | 16592225 | [2] | BOLT,M8 x 55mm | TORM8X55 mm |
| 7. | 16592525 | [2] | BOLT,M8 x 1.25 x 70mm | TORM8X70 mm |
| 8. | 16673735 | [4] | BOLT,Hex, M8 x 1.25 x 25mm | TOR Superseded by part number: 10278301 |
| 9. | 500388917 | [1] | TUBE | AST |
| 10. | 500388968 | [1] | GASKET | AST |
| 11. | 16586325 | [3] | BOLT,Hex, M8 x 20mm, Cl 8.8 | TORM8X1,25X20 Superseded by part number: 16673635 |
| 12. | 2852323 | [1] | SCREW | TORM8 x 14 Superseded by part number: 16597925 |
