纽荷兰零件查询(F3DFA613B E004) - ENGINE 504384986 - 84550912 W/O BRAKE (55.100.05) - MOTOR ELECTRIC INSTALLATION (504386635 - 5801392635) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
251 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 5801392632 | [1] | | WIRE HARNESS |
| 3. | 18177598 | [2] | | BRACKET |
| 4. | 504000061 | [1] | COLLAR | ZED |
| 5. | 504000063 | [1] | COLLAR | ZED |
| 6. | 504023286 | [1] | CLIP,200mm L | AST |
| 7. | 16585625 | [2] | SCREW,Hex, M6 x 12mm | TOR |
| 8. | 10450990 | [1] | CLAMP,26mm, Coat, 9mm Bolt Hole, P Type | LEC Superseded by part number: 86637977 |
| 9. | 16596925 | [1] | BOLT,M6 x 12mm | AST |
| 10. | 99455033 | [3] | CLAMP | TOR |
| 11. | 504052515 | [4] | RETAINER | TOR |
