现代零件查询HLF20/25/30-5 MAST HYDRAULIC PIPING(TF-MAST,NEW)EPC Hyundai _现代Hyundai_工程机械

Pos.	Part No	Qty	Parts name	Comments
.	@	[1]	MAST HYERAULIC PIPING	HLF20-5
.	@	[1]	MAST HYERAULIC PIPING	HLF25-5
.	@	[1]	MAST HYERAULIC PIPING	HLF30-5
1.	31FG-05000	[1]	FLOW REGULATOR	HLF20/25-5
1.	31FG-05100	[1]	FLOW REGULATOR	HLF30-5
2.	31FG-05200	[1]	VELOCITY FUSE VALVE
5.	EE19170100	[1]	DOWN SAFETY VALVE
6.	P910-104025	[1]	HOSE ASSY-ORFS 0X0	TF370,HLF20-5
6.	P910-104032	[1]	HOSE ASSY-ORFS 0X0	TF370,HLF20-5
6.	P910-104025	[1]	HOSE ASSY-ORFS 0X0	TF370,HLF25-5
6.	P910-104032	[1]	HOSE ASSY-ORFS 0X0	TF370,HLF25-5
6.	P910-104025	[1]	HOSE ASSY-ORFS 0X0	TF370,HLF30-5
6.	P910-104032	[1]	HOSE ASSY-ORFS 0X0	TF370,HLF30-5
6.	P910-104029	[1]	HOSE ASSY-ORFS 0X0	TF400,HLF20-5
6.	P910-104034	[1]	HOSE ASSY-ORFS 0X0	TF400,HLF20-5
6.	P910-104029	[1]	HOSE ASSY-ORFS 0X0	TF400,HLF25-5
6.	P910-104034	[1]	HOSE ASSY-ORFS 0X0	TF400,HLF25-5
6.	P910-104029	[1]	HOSE ASSY-ORFS 0X0	TF400,HLF30-5
6.	P910-104034	[1]	HOSE ASSY-ORFS 0X0	TF400,HLF30-5
6.	P910-104033	[1]	HOSE ASSY-ORFS 0X0	TF430,HLF20-5
6.	P910-104036	[1]	HOSE ASSY-ORFS 0X0	TF430,HLF20-5
6.	P910-104033	[1]	HOSE ASSY-ORFS 0X0	TF430,HLF25-5
6.	P910-104036	[1]	HOSE ASSY-ORFS 0X0	TF430,HLF25-5
6.	P910-104033	[1]	HOSE ASSY-ORFS 0X0	TF430,HLF30-5
6.	P910-104036	[1]	HOSE ASSY-ORFS 0X0	TF430,HLF30-5
6.	P910-104036	[1]	HOSE ASSY-ORFS 0X0	TF450,HLF20-5
6.	P910-104038	[1]	HOSE ASSY-ORFS 0X0	TF450,HLF20-5
6.	P910-104036	[1]	HOSE ASSY-ORFS 0X0	TF450,HLF25-5
6.	P910-104038	[1]	HOSE ASSY-ORFS 0X0	TF450,HLF25-5
6.	P910-104036	[1]	HOSE ASSY-ORFS 0X0	TF450,HLF30-5
6.	P910-104038	[1]	HOSE ASSY-ORFS 0X0	TF450,HLF30-5
6.	P910-104038	[1]	HOSE ASSY-ORFS 0X0	TF470,HLF20-5
6.	P910-104039	[1]	HOSE ASSY-ORFS 0X0	TF470,HLF20-5
6.	P910-104038	[1]	HOSE ASSY-ORFS 0X0	TF470,HLF25-5
6.	P910-104039	[1]	HOSE ASSY-ORFS 0X0	TF470,HLF25-5
6.	P910-104038	[1]	HOSE ASSY-ORFS 0X0	TF470,HLF30-5
6.	P910-104039	[1]	HOSE ASSY-ORFS 0X0	TF470,HLF30-5
6.	P910-104042	[1]	HOSE ASSY-ORFS 0X0	TF500,HLF20-5
6.	P910-104041	[1]	HOSE ASSY-ORFS 0X0	TF500,HLF20-5
6.	P910-104042	[1]	HOSE ASSY-ORFS 0X0	TF500,HLF25-5
6.	P910-104041	[1]	HOSE ASSY-ORFS 0X0	TF500,HLF25-5
6.	P910-104042	[1]	HOSE ASSY-ORFS 0X0	TF500,HLF30-5
6.	P910-104041	[1]	HOSE ASSY-ORFS 0X0	TF500,HLF30-5
6.	P910-104050	[1]	HOSE ASSY-ORFS 0X0	TF550,HLF20-5
6.	P910-104045	[1]	HOSE ASSY-ORFS 0X0	TF550,HLF20-5
6.	P910-104050	[1]	HOSE ASSY-ORFS 0X0	TF550,HLF25-5
6.	P910-104045	[1]	HOSE ASSY-ORFS 0X0	TF550,HLF25-5
6.	P910-104050	[1]	HOSE ASSY-ORFS 0X0	TF550,HLF30-5
6.	P910-104045	[1]	HOSE ASSY-ORFS 0X0	TF550,HLF30-5
6.	P910-104058	[1]	HOSE ASSY-ORFS 0X0	TF600,HLF20-5
6.	P910-104049	[1]	HOSE ASSY-ORFS 0X0	TF600,HLF20-5
6.	P910-104058	[1]	HOSE ASSY-ORFS 0X0	TF600,HLF25-5
6.	P910-104049	[1]	HOSE ASSY-ORFS 0X0	TF600,HLF25-5
6.	P910-104058	[1]	HOSE ASSY-ORFS 0X0	TF600,HLF30-5
6.	P910-104049	[1]	HOSE ASSY-ORFS 0X0	TF600,HLF30-5
6.	P910-104065	[1]	HOSE ASSY-ORFS 0X0	TF650,HLF20-5
6.	P910-104053	[1]	HOSE ASSY-ORFS 0X0	TF650,HLF20-5
6.	P910-104065	[1]	HOSE ASSY-ORFS 0X0	TF650,HLF25-5
6.	P910-104053	[1]	HOSE ASSY-ORFS 0X0	TF650,HLF25-5
6.	P910-104065	[1]	HOSE ASSY-ORFS 0X0	TF650,HLF30-5
6.	P910-104053	[1]	HOSE ASSY-ORFS 0X0	TF650,HLF30-5
6.	P910-104073	[1]	HOSE ASSY-ORFS 0X0	TF700,HLF20-5
6.	P910-104057	[1]	HOSE ASSY-ORFS 0X0	TF700,HLF20-5
6.	P910-104073	[1]	HOSE ASSY-ORFS 0X0	TF700,HLF25-5
6.	P910-104057	[1]	HOSE ASSY-ORFS 0X0	TF700,HLF25-5
6.	P910-104073	[1]	HOSE ASSY-ORFS 0X0	TF700,HLF30-5
6.	P910-104057	[1]	HOSE ASSY-ORFS 0X0	TF700,HLF30-5
7.	34FG-84010	[1]	HOSE ASSY-ORFS 0X0
8.	33FG-83000	[1]	HOSE ASSY
9.	34FG-81001	[1]	PIPE WA	TF370
9.	34FG-81011	[1]	PIPE WA	TF400
9.	34FG-81021	[1]	PIPE WA	TF430
9.	34FG-81031	[1]	PIPE WA	TF450
9.	34FG-81041	[1]	PIPE WA	TF470
9.	34FG-81051	[1]	PIPE WA	TF500,HLF20-5
9.	34FG-85050	[1]	PIPE WA	TF500,HLF20-5
9.	34FG-81051	[1]	PIPE WA	TF500,HLF25-5
9.	34FG-85050	[1]	PIPE WA	TF500,HLF25-5
9.	34FG-81051	[1]	PIPE WA	TF500,HLF30-5
9.	34FG-85050	[1]	PIPE WA	TF500,HLF30-5
9.	34FG-81061	[1]	PIPE WA	TF550,HLF20-5
9.	34FG-85060	[1]	PIPE WA	TF550,HLF20-5
9.	34FG-81061	[1]	PIPE WA	TF550,HLF25-5
9.	34FG-85060	[1]	PIPE WA	TF550,HLF25-5
9.	34FG-81061	[1]	PIPE WA	TF550,HLF30-5
9.	34FG-85060	[1]	PIPE WA	TF550,HLF30-5
9.	34FG-81071	[1]	PIPE WA	TF600,HLF20-5
9.	34FG-85070	[1]	PIPE WA	TF600,HLF20-5
9.	34FG-81071	[1]	PIPE WA	TF600,HLF25-5
9.	34FG-85070	[1]	PIPE WA	TF600,HLF25-5
9.	34FG-81071	[1]	PIPE WA	TF600,HLF30-5
9.	34FG-85070	[1]	PIPE WA	TF600,HLF30-5
9.	34FG-81081	[1]	PIPE WA	TF650,HLF20-5
9.	34FG-85080	[1]	PIPE WA	TF650,HLF20-5
9.	34FG-81081	[1]	PIPE WA	TF650,HLF25-5
9.	34FG-85080	[1]	PIPE WA	TF650,HLF25-5
9.	34FG-81081	[1]	PIPE WA	TF650,HLF30-5
9.	34FG-85080	[1]	PIPE WA	TF650,HLF30-5
9.	34FG-81091	[1]	PIPE WA	TF700,HLF20-5
9.	34FG-85090	[1]	PIPE WA	TF700,HLF20-5
9.	34FG-81091	[1]	PIPE WA	TF700,HLF25-5
9.	34FG-85090	[1]	PIPE WA	TF700,HLF25-5
9.	34FG-81091	[1]	PIPE WA	TF700,HLF30-5
9.	34FG-85090	[1]	PIPE WA	TF700,HLF30-5
10.	34FG-82001	[1]	PIPE WA	HLF20-5
10.	34FG-82002	[1]	PIPE WA	HLF20-5
10.	34FG-82001	[1]	PIPE WA	HLF25-5
10.	34FG-82002	[1]	PIPE WA	HLF25-5
10.	34FG-82001	[1]	PIPE WA	HLF30-5
10.	34FG-82002	[1]	PIPE WA	HLF30-5
11.	P760-013075	[2]	HOSE-RUBBER LOW	TF370
11.	P760-013085	[2]	HOSE-RUBBER LOW	TF400
11.	P760-013095	[2]	HOSE-RUBBER LOW	TF430
11.	P760-013105	[2]	HOSE-RUBBER LOW	TF450
11.	P760-013110	[2]	HOSE-RUBBER LOW	TF470
11.	P760-013120	[2]	HOSE-RUBBER LOW	TF500
11.	P760-013140	[2]	HOSE-RUBBER	TF550
11.	P760-013160	[2]	HOSE-RUBBER LOW	TF600
11.	P760-013180	[2]	HOSE-RUBBER,LOW	TF650
11.	P760-013200	[2]	HOSE-RUBBER,TRI.MAST(530)	TF700
12.	FMB0200610	[1]	PULLEY-HOSE
13.	S731-020025	[1]	BUSHING-DU
14.	FMB0201150	[1]	PIN-HOSE PULLEY
15.	S017-100552	[1]	BOLT-HEX
16.	232110000	[1]	WASHER
17.	S411-100002	[1]	WASHER-SPRING	HLF20-5
17.	S411-100002	[3]	WASHER-SPRING	HLF20-5
17.	S411-100002	[1]	WASHER-SPRING	HLF25-5
17.	S411-100002	[3]	WASHER-SPRING	HLF25-5
17.	S411-100002	[1]	WASHER-SPRING	HLF30-5
17.	S411-100002	[3]	WASHER-SPRING	HLF30-5
18.	F12500182	[1]	CLAMP-F/REG
19.	S035-082032	[7]	BOLT-W/WASHER
20.	X820-085353	[1]	TEE-R/TYPE,ORFS
21.	31FG-80501	[1]	TEE-RETURN
22.	X520-110023	[1]	ELBOW-90,ORFS
23.	S631-018004	[1]	O-RING
24.	S631-024004	[1]	O-RING
25.	S621-014001	[2]	O-RING
26.	S037-102022	[3]	BOLT-W/WASHER	HLF20-5
26.	S037-102022	[1]	BOLT-W/WASHER	HLF20-5
26.	S037-102022	[3]	BOLT-W/WASHER	HLF25-5
26.	S037-102022	[1]	BOLT-W/WASHER	HLF25-5
26.	S037-102022	[3]	BOLT-W/WASHER	HLF30-5
26.	S037-102022	[1]	BOLT-W/WASHER	HLF30-5
27.	S520-015000	[4]	CLAMP-HOSE
28.	S552-102370	[4]	CLAMP-BAND
29.	31FA-80110	[4]	CLAMP-HOSE
30.	34FG-83010	[1]	PLATE WA	HLF20-5
30.	34FG-83011	[1]	PLATE WA	HLF20-5
30.	34FG-83010	[1]	PLATE WA	HLF25-5
30.	34FG-83011	[1]	PLATE WA	HLF25-5
30.	34FG-83010	[1]	PLATE WA	HLF30-5
30.	34FG-83011	[1]	PLATE WA	HLF30-5
31.	S621-016001	[1]	O-RING
32.	S017-100202	[2]	BOLT-HEX	HLF20-5
32.	S017-100202	[2]	BOLT-HEX	HLF25-5
32.	S017-100202	[2]	BOLT-HEX	HLF30-5
33.	S441-100002	[2]	WASHER-HARDENED	HLF20-5
33.	S441-100002	[2]	WASHER-HARDENED	HLF25-5
33.	S441-100002	[2]	WASHER-HARDENED	HLF30-5
34.	34FG-86000	[1]	PIPE WA	HLF20-5
34.	34FG-86000	[1]	PIPE WA	HLF25-5
34.	34FG-86000	[1]	PIPE WA	HLF30-5
