神钢零件查询(6D14-T) - MITSUBISHI DIESEL ENGINES - K907D & K907LC EXCAVATORS (1/86-12/06) (01-009) - CONNECTING ROD & BEARING Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
656 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-5. | VAME032546 | [6] | LINK CONROD | KOBCONNECTING ROD ASSY(FOR M0 ONLY) Superseded by part number: 77269089, VAME072119 |
| 1-5. | VAME047040 | [6] | CONNECTING ROD ASSY(FOR M5 ONLY) | |
| 1. | NSS | [6] | NOT SOLD SEPARAT | CONROD,CONNECTING |
| 2. | NSS | [6] | NOT SOLD SEPARAT | CONCAP,CONN-ROD |
| 3. | VAME032553 | [12] | SCREW | KOBBOLT |
| 4. | VAME032042 | [12] | NUT | KOBNUT Superseded by part number: 132467A1 |
| 5. | VAME033943 | [6] | BUSHING | KOBBUSHING,CONN-ROD,8401- (FOR M0 ONLY) |
| 5. | VAME032014 | [6] | BUSHING BUSHING,CONN-ROD ,-8312 (FOR M0 ONLY) | BUSHING BUSHING,CONN-ROD ,-8312 (FOR M0 ONLY) |
| 5. | VAME072018 | [6] | BUSHING,CONN-ROD,(ME047039)(FOR M5 ONLY) | |
| 6. | VAME032518 | [1] | SET OF STD MAIN BRGS | KOBCONN-ROD BEARING SET,ONE MODEL STD (ME032417)(FOR M0 ONLY) Superseded by part number: VAME997367 |
| 6. | VAME999550 | [1] | CONN-ROD BEARING SET,ONE MODELSTD (FOR M5 ONLY) | |
| 6. | VAME032519 | [1] | BEARING LINER | KOBCONN-ROD BEARING SET,ONE MODEL US 0.25(FOR M0 ONLY) Superseded by part number: VAME997368 |
| 6. | VAME999551 | [1] | CONN-ROD BEARING SET,ONE MODEL US 0.25 (FOR M5 ONLY) | |
| 6. | VAME032520 | [1] | BEARING LINER | KOBCONN-ROD BEARING SET,ONE MODEL US 0.50 (FOR M0 ONLY) Superseded by part number: VAME999896 |
| 6. | VAME999552 | [1] | CONN-ROD BEARING SET,ONE MODEL US 0.50 (FOR M5 ONLY) | |
| 6. | VAME032521 | [1] | BEARING LINER | KOBCONN-ROD BEARING SET,ONE MODELUS 0.75 (FOR M0 ONLY) |
| 6. | VAME999553 | [1] | CONN-ROD BEARING SET,ONE MODEL US 0.75 (FOR M5 ONLY) | |
| 6. | VAME032522 | [1] | BEARING LINER | KOBCONN-ROD BEARING SET,ONE MODELUS 1.00 (FOR M0 ONLY) |
| 6. | VAME999554 | [1] | CONN ROD BEARING CONN-ROD BEARING SET,ONE MODEL US 1.00 (FOR M5 ONLY) | CONN ROD BEARING CONN-ROD BEARING SET,ONE MODEL US 1.00 (FOR M5 ONLY) |
