纽荷兰零件查询(F4DFE613J A004) - ENGINE - 84182025 (10.001.02) - CRANKCASE New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
597 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2831313 | [1] | CYLINDER BLOCK,6 Cylinders | TORASSY |
| 2. | 4895605 | [2] | HEX SOCKET PLUG,M14 x 1.5 | TORASSY |
| 3. | 4899115 | [1] | O-RING,2.2mm Thk x 11.3mm ID | TOR |
| 4. | 4899009 | [3] | PLUG,M10 x 1.5 | TORASSY |
| 5. | 4899072 | [1] | O-RING,1.6mm Thk x 8.1mm ID | TOR |
| 6. | 4895392 | [3] | HEX SOCKET PLUG,M18 x 1.5 | TORASSY |
| 7. | 4895393 | [1] | O-RING,2.2mm Thk x 15.3mm ID | TOR |
| 8. | 4895049 | [2] | DOWEL,M16.05 x 10 | TOR |
| 9. | 4894218 | [6] | SCREW,Special, M8 x 20 | TOR |
| 10. | 4899026 | [14] | DOWEL,M18 x 10 | TOR |
| 11. | 4895039 | [2] | EXPANSION PLUG,M17.73 | TOR |
| 12. | 4895038 | [6] | EXPANSION PLUG,M58.06 | TOR |
| 13. | 4895228 | [3] | EXPANSION PLUG,35.23mm x 7.94mm | TOR |
| 14. | 4891353 | [14] | SCREW,Flg Hd, M12 x 1.5 x 120 | TOR |
| 15. | 4895040 | [1] | BUSHING,54.39mm ID x 59.39mm OD x 25.4mm L | TOR |
| 16. | 4891226 | [12] | TAPPET | LEC |
| 17. | 2852202 | [6] | PISTON COOLING NOZZLE | TORASSY Superseded by part number: 504054307 |
| 18. | 2831364 | [1] | LUBE OIL NOZZLE | TORLUBE OIL JET NOZZLE |
