纽荷兰零件查询(F4DFE613J A004) - ENGINE - 84182025 (10.206.01) - FUEL FILTER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
435 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 84366486 | [1] | ASSY | FILTER ASSY |
| 2. | 2852247 | [3] | BOLT,Hex, M8 x 1.25 x 30mm | TORM8 x 30 |
| 3. | 84366489 | [1] | | FEED PUMP |
| 4. | 4897224 | [1] | SENSOR | TORTemperature |
| 5. | 84366488 | [2] | | VALVE |
| 6. | 2854563 | [5] | FITTING | TOR Superseded by part number: 504210082 |
| 7. | 4894721 | [6] | SEALING WASHER,12.2mm ID x 17mm OD x 1.5mm Thk | TOR |
| 8. | 2854564 | [1] | FITTING | TOR |
| 9. | 4897897 | [1] | FUEL FILTER | BHB Superseded by part number: 87803197, 87803197, 87803200, 87803197, 87803200, 87803208, 87803197, 87803200, 87803208, 87803209 |
| 10. | 84278636 | [1] | | FUEL FILTER,w/water in fuel sensor, M14 |
| 11. | 2830375 | [1] | ADAPTER | TOR |
| 12. | 2853585 | [1] | SENSOR | TORM8 x 25 Superseded by part number: 2830987 |
| 13. | 2830459 | [1] | ADAPTER | TOR |
| 14. | 84366491 | [1] | | SPRING |
