| 1-28. | VAME038750 | [1] | TURBOCHARGER ASSY TC06-17A(FOR M0 ONLY) | |
| 1-28. | VAME038755 | [1] | TURBOCHARGER ASSY TC06-17A(FOR M1 ONLY) | |
| 1-28. | VAME033536 | [1] | TURBOCHARGER ASSY TC06-17B(FOR M2 ONLY) | |
| 1-28. | VAME037700 | [1] | TURBOCHARGER ASSY TD06-17A(FOR M5 ONLY) | |
| 1-28. | VAME037701 | [1] | TURBOCHARGER | KOBTURBOCHARGER ASSY TD06-17A(FOR M6 ONLY) |
| 1. | VAME719617 | [1] | COVER,COMPR(FOR M0,M1,M5,M6 ONLY) | |
| 1. | VAME719691 | [1] | COVER,COMPR(FOR M2 ONLY) | |
| 2. | VAME719621 | [1] | LOCK NUT | KOBNUT,LOCK |
| 3. | VAME719607 | [1] | WHEELCOMPR (FOR M0,M1,M5,M6 ONLY) | |
| 3. | VAME719680 | [1] | WHEELCOMPR(FOR M2 ONLY) | |
| 4. | VAME719585 | [1] | SNAP RING | KOBRING,SNAP |
| 5. | VAMF520406 | [1] | O-RING | KOBO-RING 50(FOR M0,M1 ONLY) |
| . . | VAME719590 | [1] | O-RING | KOBO-RING 50(FOR M2,M5,M6 ONLY) |
| 6. | VAME719583 | [1] | INSERT | KOBINSERT |
| 7. | VAME719582 | [1] | DEFLECTOR | KOBDEFLECTOR,OIL |
| 8. | VAME719780 | [1] | PISTON RING | KOBRING,PISTON |
| 9. | VAME719620 | [1] | SLEEVE,THRUST(FOR M0,M1,M2 ONLY) | |
| 9. | VAME719910 | [1] | SLEEVE | KOBSLEEVE,THRUST(FOR M5,M6 ONLY) |
| 10. | VAME719581 | [1] | BEARING,THRUST(FOR M0,M1,M2 ONLY) | |
| 10. | VAME719902 | [1] | THRUST BEARING | KOBBEARING,THRUST(FOR M5,M6 ONLY) |
| 10A. | VAME719912 | [1] | THRUST RING | KOBRING,THRUST(FOR M5,M6 ONLY) |
| 11. | VAME719580 | [1] | BEARING(FOR M0,M1,M2 ONLY) | |
| 11. | VAME719900 | [2] | BEARING BEARING(FOR M5,M6 ONLY) | BEARING BEARING(FOR M5,M6 ONLY) |
| 11A. | VAME719904 | [2] | SNAP RING | KOBRING,SNAP(FOR M5,M6 ONLY) |
| 12. | VAMF520416 | [1] | O-RING | KOBO-RING 100(FOR M5,M6 ONLY) |
| 12. | VAME719627 | [1] | O-RING | KOBO-RING 100(FOR M2, M5,M6 ONLY) |
| 13. | VA4916925300 | [1] | BEARING HOUSING & PIN ASSY(FOR M0,M1 ONLY) | |
| 13. | VAME719660 | [1] | BEARING HOUSING & PIN ASSY(FOR M2 ONLY) | |
| 13. | VAME719920 | [1] | BEARING HOUSING & PIN ASSY(FOR M5,M6 ONLY) | |
| 14. | VAME719584 | [1] | SNAP RING | KOBRING,SNAP |
| 15. | VAME719570 | [1] | COUPLING | KOBCOUPLING ASSY |
| 16. | VA4916819102 | [1] | PLATE,TURBINE BACK(FOR M0,M1 ONLY) | |
| 16. | VAME719575 | [1] | PLATE PLATE,TURBINE BACK(FOR M2 ONLY) | PLATE PLATE,TURBINE BACK(FOR M2 ONLY) |
| 16. | VAME719573 | [1] | PLATE,TURBINE BACK(FOR M5,M6 ONLY) | |
| 17. | VAME719591 | [1] | RING,PISTON(FOR M0,M1,M2 ONLY) | |
| 17. | VAME719906 | [1] | PISTON RING | KOBRING,PISTON(FOR M5,M6 ONLY) |
| 18. | VAME719597 | [1] | SHAFT & TURBINE WHEEL ASSY(FOR M0,M1,M2 ONLY) | |
| 18. | VAME719924 | [1] | SHAFT | KOBSHAFT & TURBINE WHEEL ASSY(FOR M5,M6 ONLY) |
| 19. | VAME719556 | [1] | HOUSING,TURBINE 12CM2(FOR M0,M1,M5,M6 ONLY) | |
| 19. | VAME719650 | [1] | HOUSING,TURBINE12CM2(FOR M2 ONLY) | |
| 20. | VAME719690 | [1] | ACTUATOR | KOBACTUATOR,WASTE GATE(FOR M2 ONLY) |
| 21. | VAME719740 | [2] | BOLT,W/WSR 8X16(FOR M2 ONLY) | |
| 22. | VAME719574 | [1] | LEVER ASSY(FOR M2 ONLY) | |
| 23. | VAME719576 | [1] | NUT(FOR M2 ONLY) | |
| 24. | VAME719705 | [1] | PIN,SNAP 4(FOR M2 ONLY) | |
| 25. | VAME719694 | [1] | HOSE,NIPPLE(FOR M2 ONLY) | |
| 26. | VAME719630 | [2] | CLIP,HOSE(FOR M2 ONLY) | |
| 27. | VAME719624 | [1] | PLAIE NAME(FOR M0,M1,M2 ONLY) | |
| 27. | VAME719625 | [1] | PLAIE NAME(FOR M5,M6 ONLY) | |
| 28. | VAMS466101 | [2] | RIVET,SCREW 2X4.8(FOR M0,M1,M2 ONLY) | |
| 28. | VAME719761 | [2] | RIVET,SCREW 2X4.8(FOR M5,M6 ONLY) | |
