神钢零件查询(6D14-T) - MITSUBISHI DIESEL ENGINES - K907D & K907LC EXCAVATORS (1/86-12/06) (01-024) - ENGINE ATTACHING PARTS Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
508 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME031944 | [1] | COVER | KOBCOVER,SIDE Superseded by part number: VAME071320 |
| 2. | VAME030900 | [1] | COVER, SIDE COVER,SIDE | COVER, SIDE COVER,SIDE |
| 3. | VAME031155 | [2] | GASKET | KOBGASKET,SIDE COVER Superseded by part number: 77269054, VAME071274 |
| 4. | VAMF140221 | [16] | BOLT | KOBBOLT,FLANGE 8X12 |
| 5. | VAMH037720 | [1] | PLUG DRAIN PLUG (FOR M0 ONLY) | PLUG DRAIN PLUG (FOR M0 ONLY) |
| 5. | VAME031455 | [1] | COCK | KOBCOCK,WATER DRAIN (FOR M5 ONLY) |
| 5. | VAMF660068 | [1] | PACKING | KOBGASKET 20 (FOR M0 ONLY) Superseded by part number: VAF420220000 |
| 6. | VA3110704800 | [1] | PIPE DRAIN PIPE,DRAIN L=300 (FOR M5 ONLY) | PIPE DRAIN PIPE,DRAIN L=300 (FOR M5 ONLY) |
| 7. | VAMS666040 | [1] | CLAMP | KOBCLAMP 16 (FOR M5 ONLY) |
| 8. | VAME031058 | [1] | CAP | KOBCAP,SEALING |
| 9. | VAME031087 | [1] | SET OF SCREWS | KOBSCREW,SET |
| 9. | VAMF660063 | [1] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 10. | VAMH038306 | [1] | CONNECTOR CONNECTOR,FOR TURBOCHARGER M10-M14 | CONNECTOR CONNECTOR,FOR TURBOCHARGER M10-M14 |
| 10. | VAMF660063 | [1] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 11. | VAME031088 | [1] | PLUG | KOBPLUG |
| 11. | VAMF660063 | [1] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
