Pos.	Part No	Qty	Parts name	Comments
010.	6C04036300	[1]	ASSY PUMP,HYDRAULIC	; <=YX0866 2.6400(lbs); 1.200
010.	6C04036306	[1]	ASSY PUMP,HYDRAULIC	; >=YY0001 2.8160(lbs); 1.280
020.	6C04036361	[1]	COVER	; >=10001 0.0000(lbs); 0.000
020.	K351136751	[1]	COVER	; >=25929 0.0000(lbs); 0.000
020.	K351136752	[1]	COVER	; >=56403 0.0000(lbs); 0.000
020.	6A10037502	[1]	SPRING	; >=82938 0.5720(lbs); 0.260
030.	6C04036391	[1]	CMP.GEAR,HYD.PUMP	; <=741870 0.0000(lbs); 0.000
030.	6C04036390	[1]	COMP.GEAR,HYD.PUMP	; >=10001 0.1320(lbs); 0.060
030.	6C04036392	[1]	COMP.GEAR	; >=82938 0.6798(lbs); 0.309
040.	6C04036351	[1]	PLATE,SIDE	; >=10001 0.0000(lbs); 0.000
040.	6C04036352	[1]	PLATE,SIDE	; >=56403 0.0506(lbs); 0.023
045.	6A10037230	[2]	BUSH	; >=82938 0.0110(lbs); 0.005
050.	6C04036341	[1]	RING,DOUBLE	; >=10001 0.0000(lbs); 0.000
050.	6C04036342	[1]	RING,DOUBLE	; >=56403 0.0066(lbs); 0.003
060.	6A10037230	[2]	BUSH	; >=82938 0.0110(lbs); 0.005
060.	6C04036371	[4]	BUSH	; >=10001 0.0000(lbs); 0.000
060.	6A10037231	[4]	BUSH	; >=25929 0.0000(lbs); 0.000
070.	3138176390	[1]	SEAL,OIL	0.0220(lbs); 0.010
080.	0461100300	[1]	CIR-CLIP,INTERNAL	0.0088(lbs); 0.004
090.	0175451030	[4]	BOLT,FLANGE	0.0660(lbs); 0.030
100.	0501200814	[2]	PIN,STRAIGHT	0.0132(lbs); 0.006
