现代零件查询HLF20/25/30-5 BRAKE MASTER CYLINDEREPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
574 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
FAC0600291
|
[1] |
MASTER CYLINDER
|
|
| 1. |
XKBS-00002
|
[1] |
BODY
|
|
| K2. |
XKBS-00003
|
[1] |
PISTON
|
|
| NK3. |
XKBS-00004
|
[1] |
CUP.PRIMARY
|
|
| K4. |
XKBS-00005
|
[1] |
CUP.SECONDARY
|
|
| K5. |
XKBS-00006
|
[1] |
SPRING
|
|
| K6. |
XKBS-00007
|
[1] |
SEAT.SPRING
|
|
| K7. |
XKBS-00008
|
[1] |
SPACER
|
|
| K8. |
XKBS-00009
|
[1] |
PLATE
|
|
| K9. |
XKBS-00010
|
[1] |
RING.RETAINING
|
|
| 10. |
XKBS-00011
|
[1] |
BOOT
|
|
| K11. |
XKBS-00012
|
[1] |
VALVE.CHECK
|
|
| K12. |
XKBS-00013
|
[1] |
SEAT.VALVE
|
|
| 13. |
XKBS-00014
|
[1] |
ROD
|
|
| 14. |
XKBS-00015
|
[1] |
YOKE
|
|
| 15. |
XKBS-00016
|
[1] |
NUT
|
|
| 16. |
XKBS-00017
|
[1] |
NIPPLE
|
|
| 17. |
XKBS-00018
|
[1] |
BAND
|
|
| 18. |
XKBS-00019
|
[1] |
BOLT.BAND
|
|
| 19. |
XKBS-00020
|
[1] |
PLATE.BAND
|
|
| 20. |
XKBS-00021
|
[1] |
WASHER.BAND
|
|
| N21. |
XKBS-00022
|
[1] |
CAP
|
|
| N22. |
XKBS-00023
|
[3] |
CAP
|
|
| K. |
F12330010
|
[1] |
SEAL KIT
|
|
