| 1. |
700124977
|
[1] |
ANGLE
|
CAS
|
| 2. |
700715705
|
[1] |
DECAL
|
CAS
- operational
|
| 3. |
700711411
|
[1] |
CYLINDER
|
CAS
ASSEMBLY - hydraulic
|
| 4. |
700704639
|
[1] |
PLUG
|
CAS
- vented
|
| 5. |
7791916
|
[1] |
ELBOW
|
CAS
- 90 degrees (Includes item 23)
|
| 6. |
700124976
|
[1] |
LINK
|
HFI
STRAP
|
| 7. |
218-5105
|
[1] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
- 90 degrees (Includes item 23) Superseded by part number: 76344, 72186128
|
| 9. |
496-11028
|
[1] |
WASHER,9/32" x 5/8" x .065, HDN
|
CAS
1/4 HARDENED PLAIN WASHER Superseded by part number: 86632587
|
| 10. |
1703354
|
[1] |
NUT
|
IH
1/4-20 HFTLN GR/G
|
| 11. |
7021728
|
[2] |
STRAP
|
CAS
TIE - cable Superseded by part number: 529070, 529070, NLS
|
| 12. |
700711345
|
[1] |
VALVE
|
CAS
- needle
|
| 13. |
218-483
|
[2] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 1/4" - 18 Male NPTF
|
CAS
1/4 X 90 DEGREE ELBOW Superseded by part number: 578384
|
| 14. |
700136007
|
[1] |
PLATE
|
HFI
- mounting
|
| 15. |
7796840
|
[1] |
HOSE
|
HFI
- hydraulic
|
| 16. |
413-848
|
[1] |
BOLT,Hex, 1/2" - 13 x 3", Gr 5
|
IH
1/2-13 X 3 C Superseded by part number: 72187218, 87339
|
| 17. |
705541
|
[2] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 18. |
231-5348
|
[1] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 19. |
241-1316
|
[1] |
LINK,19.05mm Pitch
|
CAS
LINK - connector, #60 (W/spring clip)
|
| 20. |
241-1116
|
[1] |
LINK,Chain, 19.05mm Pitch
|
CAS
CHAIN - link, R/C #60 Superseded by part number: 86595251
|
| 21. |
Q3947
|
[1] |
KEY,Gib, 3/8" Sq x 1 1/2"
|
IH
3/8 X 1-1/2 GIB KEY
|
| 22. |
700124968
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET WA - 60B22 tooth
|
| 23. |
738468
|
[2] |
O-RING
|
IH
|
| 8. |
413-420
|
[1] |
BOLT,Hex, 1/4" - 20 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 87716, 72187191
|
