| 1. |
433-512
|
[6] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 2. |
232-5315
|
[20] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 3. |
413-1228
|
[1] |
BOLT,Hex, 3/4" - 10 x 1-3/4", Gr 5
|
CAS
3/4-10 x 1-3/4 C Superseded by part number: 88725
|
| 4. |
492-11075
|
[1] |
LOCK WASHER,3/4"
|
CAS
3/4" Superseded by part number: 87340
|
| 5. |
705566
|
[1] |
WASHER
|
IH
3/4 HARDENED PLAIN WASHER
|
| 6. |
700100927
|
[1] |
HUB
|
L
|
| 7. |
8050825
|
[1] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
- cylindrical Superseded by part number: F82059
|
| 8. |
409-7612
|
[2] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 9. |
232-5316
|
[13] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 10. |
700130715
|
[1] |
ROLLER
|
CAS
WA - drive (Includes items 6 & 7)
|
| 11. |
663562R1
|
[2] |
FLANGE
|
IH
|
| 12. |
50468
|
[1] |
SPHERICAL BEARING,38.1 mm ID x 80 mm OD x 22, 43.66 mm
|
IH
- spherical
|
| 13. |
360-816
|
[3] |
BOLT,Hex, 1/2" - 13 x 1", Gr 8
|
CAS
1/2-13 X 1 HFS GR8 Superseded by part number: 87034823
|
| 14. |
705541
|
[3] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 15. |
700714214
|
[1] |
SHEAVE
|
CAS
- steel
|
| 16. |
T13450
|
[1] |
KEY
|
CAS
1/4 X 1-1/4 KEY
|
| 17. |
700714215
|
[1] |
V-BELT,1066.80 mm L
|
CAS
|
| 18. |
121-226
|
[3] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 19. |
700130721
|
[1] |
SHIELD
|
CAS
|
| 20. |
413-612
|
[1] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 72187204, 86500692
|
| 21. |
492-11038
|
[1] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 22. |
700710049
|
[2] |
WASHER
|
CAS
3/8 FENDER WASHER
|
| 23. |
413-864
|
[1] |
BOLT,Hex, 1/2" - 13 x 4", Gr 5
|
CAS
1/2-13 X 4 C Superseded by part number: 86505993
|
| 24. |
80679
|
[1] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 25. |
6598684
|
[1] |
BUSHING
|
CAS
SPACER
|
| 26. |
700130720
|
[1] |
ADAPTER
|
CAS
SPACER
|
| 27. |
121-115
|
[8] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 28. |
700714564
|
[28] |
SCREW
|
CAS
5/16-18 X 1 CRFCHTCTS Superseded by part number: 166481
|
| 29. |
700125908
|
[4] |
STRAP
|
CAS
|
| 30. |
121-237
|
[4] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
3/8-16 X 1-1/4 HFS GR8 Superseded by part number: 87327172
|
| 31. |
496-11041
|
[4] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 32. |
700125786
|
[6] |
SLIDE
|
HFI
WA
|
| 33. |
700125897
|
[1] |
SUPPORT
|
HFI
WA
|
| 34. |
413-532
|
[2] |
BOLT,Hex, 5/16" - 18 x 2", Gr 5
|
CAS
Superseded by part number: 9636711
|
| 35. |
700710880
|
[1] |
SPRING
|
CAS
- leaf
|
| 36. |
700136017
|
[1] |
SUPPORT
|
HFI
WA
|
| 37. |
413-536
|
[4] |
BOLT,Hex, 5/16" - 18 x 2-1/4", Gr 5
|
CAS
Hex, 5/16-18 X 2-1/4 C Superseded by part number: 86505972
|
| 38. |
496-21034
|
[4] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 39. |
700125793
|
[2] |
SUPPORT
|
HFI
WA
|
| 40. |
434-616
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 41. |
700125905
|
[2] |
PLATE
|
HFI
|
| 42. |
413-540
|
[2] |
BOLT,Hex, 5/16" - 18 x 2-1/2", Gr 5
|
CAS
Superseded by part number: 72187202, 88346
|
| 43. |
700130722
|
[1] |
SHIM
|
CAS
|
| 44. |
700136021
|
[1] |
SHIELD
|
HFI
|
| 45. |
413-548
|
[2] |
BOLT,Hex, 5/16" - 18 x 3", Gr 5
|
CAS
Superseded by part number: 88731
|
| 46. |
495-61034
|
[8] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
5/16 WIDE PLAIN WASHER
|
| 47. |
231-5145
|
[2] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
