| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 6V-9666 | [1] | WASHER-HARD(11X36X6-MM THK) | |
| 2. | 349-2654 | [1] | SEAL-WATER PUMP | |
| 3. | 203-3831 | [1] | PLUG-CUP | |
| 4. | 223-9143 | [1] | IMPELLER | |
| 5. | 223-9145 | [1] | HOUSING-PUMP | |
| 6. | 291-6905 | [1] | SHAFT-WATER PUMP | |
| 7. | 292-1200 | [1] | GEAR-WATER PUMP | |
| 8. | 1B-3867 | [2] | BALL BEARING | |
| 9. | 6V-5842M | [1] | BOLT(M10X1.5X40-MM) | |
| 10. | 8C-3100 | [1] | SEAL-LIP TYPE | |
| 11. | 8T-9598 | [1] | RING-RETAINING | |
| M | METRIC PART | |||
