| 1. |
700125873
|
[1] |
PIPE
|
HFI
WA
|
| 2. |
121-237
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
3/8-16 X 1-1/4 HFS GR8 Superseded by part number: 87327172
|
| 3. |
232-5316
|
[6] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 4. |
700125770
|
[1] |
LATCH
|
HFI
WA - left
|
| 5. |
51200205
|
[2] |
SPACER
|
CAS
|
| 6. |
700125777
|
[2] |
HANDLE
|
HFI
|
| 7. |
700128333
|
[1] |
SUPPORT
|
HFI
WA - left
|
| 8. |
700710877
|
[2] |
BEARING, ROLLER, CYL,15 mm ID x 35 mm OD x 11 mm
|
CAS
BEARING Superseded by part number: 84330053
|
| 9. |
700125869
|
[1] |
ROLLER ASSY.
|
CAS
ROLLER ASSEMBLY (Includes item 8)
|
| 10. |
700125776
|
[1] |
LATCH
|
HFI
WA - right
|
| 11. |
52233
|
[4] |
BUSHING
|
CAS
5/8 X 14 GAUGE NRMB Superseded by part number: 51200381
|
| 12. |
163-41
|
[4] |
SCREW,Sl Hex Wshr Hd, 5/16" - 18 x 1 1/4"
|
CAS
5/16-18 X 1-1/4 HSHMS
|
| 13. |
700711557
|
[6] |
WASHER
|
CAS
1/2 HARDENED WIDE PLAIN WASHER
|
| 14. |
232-5315
|
[25] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 15. |
432-820
|
[2] |
COTTER PIN,1/8" x 1 1/4"
|
CAS
PIN, SPLIT (COTTER), 1/8" x 1-1/4" Superseded by part number: 87395, 87778232
|
| 16. |
700128334
|
[1] |
SUPPORT
|
HFI
WA - right
|
| 17. |
121-108
|
[4] |
BOLT,Hex Flg, 5/16"-18 x 1 1/4", Serr
|
CAS
5/16-18 X 1 HWHMS
|
| 18. |
700128309
|
[1] |
PANEL
|
HFI
- floor
|
| 19. |
700125846
|
[2] |
HANGER
|
HFI
|
| 20. |
858167
|
[2] |
SPRING
|
L
- extension
|
| 21. |
700127924
|
[2] |
MOUNTING PARTS
|
CAS
MOUNTING - spool
|
| 22. |
700127926
|
[1] |
PLATE
|
HFI
|
| 23. |
164-40
|
[2] |
HEX SOC SCREW,Flat Hd, 5/16" - 18 x 3/4"
|
CAS
5/16-18 X 3/4 HSFCHCS SPL Superseded by part number: 61-43112
|
| 24. |
700127925
|
[3] |
PLATE
|
HFI
|
| 25. |
433-512
|
[5] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 26. |
434-412
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, 1/4" - 20 x 3/4", Gr 5
|
CAS
1/4-20 X 3/4 RHSNB Superseded by part number: 280638
|
| 27. |
1703354
|
[6] |
NUT
|
IH
1/4-20 HFTLN GR/G
|
| 28. |
700710878
|
[1] |
HANDLE
|
CAS
|
| 29. |
121-115
|
[4] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 30. |
256873
|
[10] |
BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd
|
NH
|
| 31. |
700128341
|
[1] |
LID
|
HFI
WA Superseded by part number: 700131955
|
| 32. |
495-61034
|
[2] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
5/16 WIDE PLAIN WASHER
|
| 33. |
434-616
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
