纽荷兰零件查询(F4GE9484D J619) - ENGINE - 5801584504 - YM02P00020P1 (11/12-) (10.304.AL) - SUCTION PIPE, ENGINE OIL New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
914 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2853397 | [1] | SUCTION PIPE | TOROil suction Superseded by part number: |
| 2. | 4895291 | [3] | SCREW,Hex Flg, M10 x 1.5 x 20 | TOR |
| 3. | 2852237 | [1] | SEALING RING | TOR Superseded by part number: 14457981 |
| 4. | 2852238 | [1] | ELBOW | TOROil suction pipe |
| 5. | 4899020 | [2] | FLANGE BOLT,Hex, M8 x 1.25 x 20mm | TOR Superseded by part number: 16673635 |
| 5. | 2852234 | [2] | FLANGE BOLT,Hex, M8 x 1.25 x 20mm | TOR Superseded by part number: 16978124 |
| 6. | 4898301 | [1] | GASKET,0.42mm Thk | TOROil suction connection |
