凯斯零件查询(8455T) - CASE IH ROUND BALER W/TRACTOR HYDRAULICS (1/92-12/97) (8-08) - HYDRAULIC CONTROL VALVE ASSEMBLY, CONT'D, 700715719 CTRL. VALVE ASSY. COMPLETE, CONT'D FROM PG. 8-6 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
192 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
149942C1
|
[6] |
SEAL KIT
|
IH
Superseded by part number: 86508168
|
| 2. |
700707833
|
[2] |
VALVE, CHECK
|
CAS
VALVE - check
|
| 3. |
700712597
|
[1] |
PISTON
|
CAS
- pilot (Includes seals)
|
| 4. |
700706152
|
[1] |
SEAL KIT
|
CAS
Superseded by part number: 47394721
|
| 5. |
700712619
|
[1] |
VALVE
|
CAS
- check
|
| 6. |
700707840
|
[2] |
PLUG
|
HFI
#6 SAE O-RING PLUG
|
| 7. |
700711693
|
[2] |
KIT
|
CAS
SERVICE KIT (Includes O-Ring Plug, Spring Guide & Ball)
|
| 8. |
700713868
|
[1] |
PLUG
|
CAS
- cavity (S.N. CFH0080366 and later)
|
| 9. |
700711136
|
[1] |
VALVE
|
CAS
- spool (S.N. CFH0080001 thru CFH0080365)
|
| 10. |
700711711
|
[1] |
SEAL KIT
|
CAS
KIT
|
| 11. |
700712631
|
[1] |
SEAL
|
CAS
KIT
|
| 12. |
700710891
|
[1] |
PISTON
|
CAS
- pilot
|
| 13. |
700709237
|
[2] |
VALVE POPPET
|
IH
VALVE - check
|
| 14. |
700707831
|
[1] |
VALVE
|
L
- check
|
