神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (01-004) - OIL PAN Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
654 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA3181392100 | [1] | ENGINE OIL PAN | KOBPAN,OIL, FOR M0 ONLY |
| 1. | VAME070197 | [1] | PAN,OIL, FOR M7 ONLY | |
| 1. | VAME047162 | [1] | PAN,OIL, FOR M8 ONLY | |
| 2. | VAMH037126 | [1] | PLUG,18mm OD x 1.5 Thd Pitch | KOBPLUG |
| . . | VAMH035018 | [1] | GASKET | KOBGASKET 18 |
| 10. | VAME034652 | [1] | GASKET | KOBGASKET, OIL. PAN,FOR M0,M7 ONLY Superseded by part number: VAME078746 |
| 11. | VAMF140225 | [35] | BOLT | KOBBOLT,FLANGE 8X20,FOR M0,M7 ONLY |
| 11. | VAMF140227 | [35] | FLANGE BOLT | KOBBOLT,FLANGE 8X25,FOR M8 ONLY |
| 13. | VAMH021013 | [1] | CLAMP CLAMP | CLAMP CLAMP |
| 14. | VA3184391100 | [1] | CLAMP FOR M0,M7 ONLY | CLAMP FOR M0,M7 ONLY |
| 18. | VAMC840577 | [1] | SWITCH | KOBOIL LEVEL,FOR M7 ONLY |
| 19. | VAMF140002 | [3] | SCREW | KOBBOLT,FLANGE 6X10,FOR M7 ONLY |
| 20-23. | VAME034363 | [1] | CUSHION & RUBBER KIT,FOR M8 ONLY | |
| 20. | VAME034701 | [1] | CUSHION,RUBBER,FOR M8 ONLY | |
| 21. | VAME034288 | [1] | PLATE,FR,FOR M8 ONLY | |
| 22. | VAME034289 | [2] | PLATE,MI,FOR M8 ONLY | |
| 23. | VAME034290 | [1] | PLATE,RE,FOR M8 ONLY | |
