凯斯零件查询(8455T) - CASE IH ROUND BALER W/TRACTOR HYDRAULICS (1/92-12/97) (7-22) - MESH WRAP ROLLER ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
465 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700124962
|
[1] |
PANEL
|
HFI
WA - left
|
| 2. |
700125821
|
[1] |
SUPPORT
|
HFI
WA - left
|
| 3. |
121-226
|
[12] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 4. |
496-81010
|
[23] |
WASHER
|
CAS
3/8 HARDENED WIDE PLAIN WASHER Superseded by part number: 86625244
|
| 5. |
232-5316
|
[12] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 6. |
700125882
|
[1] |
BUMPER
|
CAS
|
| 7. |
413-510
|
[8] |
BOLT,Hex, 5/16" - 18 x 5/8", Gr 5
|
CAS
Superseded by part number: 72187195, 9627874
|
| 8. |
492-11031
|
[8] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 9. |
496-21034
|
[9] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 10. |
700124984
|
[1] |
SUPPORT
|
CAS
|
| 11. |
700125817
|
[1] |
SUPPORT
|
HFI
WA
|
| 12. |
409-7512
|
[1] |
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
|
CAS
Hex Flg, 5/16-18 x 3/4", Serr Superseded by part number: 145913, 72187186
|
| 13. |
433-512
|
[1] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 14. |
232-5315
|
[1] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 15. |
700124983
|
[1] |
KNIFE
|
CAS
WA
|
| 16. |
700124981
|
[1] |
SUPPORT
|
CAS
|
| 17. |
700124963
|
[1] |
PANEL
|
HFI
WA - right
|
| 18. |
700125825
|
[1] |
SUPPORT
|
HFI
WA - right
|
| 19. |
700125888
|
[1] |
ROLLER ASSY.
|
CAS
ROLLER WA (Rubber) (S.N. CFH0084501 thru CFH0084585)
|
| . . |
700130746
|
[1] |
ROLLER
|
CAS
WA (Steel) (S.N. CFH0084586 and later)
|
| 20. |
51680
|
[2] |
BEARING, BALL
|
CAS
BEARING Superseded by part number: 47577183, 45396
|
| 21. |
700125892
|
[1] |
SHAFT
|
CAS
|
| 22. |
700125885
|
[1] |
ROLLER ASSY.
|
CAS
ROLLER ASSEMBLY (S.N. CFH0084501 thru CFH0084585)
|
| . . |
700127935
|
[1] |
ROLLER
|
CAS
ASM. (Overrunning clutch) (S.N. CFH0084586 and later)
|
