神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (01-024) - EXHAUST MANIFOLD Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
589 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-2. | VAME032799 | [1] | EXHAUST MANIFOLD ASSY | |
| 1. | VAME032800 | [1] | MANIFOLD,EXH | |
| 2. | VAMF407728 | [4] | STUD | KOBSTUD 10X30 Superseded by part number: 134865A1 |
| 4. | VAME033496 | [6] | GASKET | KOBGASKET,EXH MANIF Superseded by part number: VAME073957 |
| 7. | VAMH004054 | [12] | NUT | KOBFLANGE 10 Superseded by part number: 134868A1 |
| 15. | VAME033767 | [1] | INSULATOR,HEAT | |
| 16. | VAMH000392 | [4] | BOLT | KOBBOLT,W/WSR 8X12 |
