凯斯零件查询(8460) - CASE IH ROUND BALER (S/N CFH0057418 & AFTER) (1/88-12/93) (9-22) - BALE STARTING KIT, HK50579 BALE STARTING KIT COMPLETE, TO BE ORDERED THROUGH WHOLEGOODS ONLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
937 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
HK50579
|
[1] |
BALE STARTING KIT COMPLETE
|
|
| 1. |
700118818
|
[2] |
LINK
|
HFI
|
| 2. |
771949
|
[2] |
HEX SOC SCREW,Shoulder, 1/2" - 13 - 5/8" x 2 1/2", Gr 8
|
CAS
1/2-13 X 2-1/2 HSHHSS (5/8 Shank)
|
| 3. |
396-21066
|
[2] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 4. |
495-21056
|
[2] |
WASHER,1/2"
|
CAS
1/2 WIDE PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 5. |
230-4218
|
[2] |
LOCK NUT,1/2"-13, GA
|
CAS
1/2-13 HCLN
|
| 6. |
496-11041
|
[8] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 7. |
121-237
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
3/8-16 X 1-1/4 HFS GR8 Superseded by part number: 87327172
|
