沃尔沃零件查询AD30A; AQAD30A; MD30A; TAMD30A; TMD30A; AD30; AQAD30; MD30; TAMD30; TMD30TransmissionsCommercial Use Connecting Components, Reverse GearEPC Volvo Penta Parts catalog
广数供应链运营团队, 14 02月, 2025，浏览：
631 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
852502
|
[1] |
Reversing gear
|
Replaced by reverse gear-853398 and connection kit-853774
|
| 1. |
|
|
|
See group 4B
|
| 1. |
852503
|
[1] |
Reversing gear
|
Replaced by reverse gear-853399 and connection kit-853774, Ratio 2,73:1
|
| 2. |
829489
|
[1] |
Cap
|
|
| 2A. |
955319
|
[11] |
Hexagon screw
|
|
| 2B. |
941908
|
[11] |
Spring washer
|
|
| 2C. |
803901
|
[1] |
Connection flange
|
|
| 3. |
955319
|
[6] |
Hexagon screw
|
|
| 4. |
941908
|
[6] |
Spring washer
|
|
| 5. |
847105
|
[1] |
Pipe
|
|
| 6. |
949315
|
[1] |
Rubber hose
|
L=680mm
|
| 7. |
948210
|
[1] |
Cable tie
|
|
| 8. |
846051
|
[1] |
Coolant pipe
|
|
| 9. |
944386
|
[1] |
Rubber hose
|
L=60mm
|
| 10. |
994560
|
[2] |
Hose clamp
|
|
| 11. |
845792
|
[1] |
Connecting hook
|
|
| 12. |
994560
|
[4] |
Hose clamp
|
|
| 13. |
949658
|
[1] |
O-ring
|
(925061)
|
| 14. |
847105
|
[1] |
Pipe
|
|
| 15. |
847108
|
[1] |
Pipe retainer
|
|
| 16. |
963545
|
[2] |
Hexagon screw
|
|
| 17. |
847107
|
[1] |
Lock brace
|
|
| 18. |
829516
|
[1] |
Engine bracket
|
S.B
|
| 18. |
829515
|
[1] |
Engine bracket
|
P
|
| 19. |
955341
|
[5] |
Hexagon screw
|
|
| 20. |
940143
|
[6] |
Toothed washer
|
|
| 21. |
846764
|
[4] |
Rubber element
|
|
| 22. |
955900
|
[4] |
Washer
|
|
| 23. |
955805
|
[8] |
Hexagon nut
|
|
| 24. |
941912
|
[4] |
Spring washer
|
|
| 25. |
191940
|
[6] |
Washer
|
|
| 26. |
955900
|
[2] |
Washer
|
|
| 27. |
846023
|
[1] |
Injection pump
|
|
| 27. |
|
|
|
See group 2C
|
