| 1. |
57596
|
[1] |
BELT
|
L
V-BELT
|
| 2. |
861088
|
[2] |
BUCKET TOOTH KEY
|
IH
1/2 X 2 KEY - gib
|
| 3. |
700116042
|
[1] |
SHEAVE
|
CAS
WA
|
| 4. |
6867659
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET WA - 60B40 tooth
|
| 5. |
611362R91
|
[1] |
CHAIN (AG)
|
IH
CHAIN - roller, #60 (10 Foot bulk) Superseded by part number: 611362R91X
|
| 6. |
241-1316
|
[1] |
LINK,19.05mm Pitch
|
CAS
LINK - connector, #60 (W/Spring clip)
|
| 7. |
249-1
|
[1] |
KEY
|
IH
1/4 X 1-3/4 KEY - gib
|
| 8. |
85951
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET - 60B20 tooth
|
| 9. |
541857R92
|
[1] |
SPROCKET,15T
|
IH
- idler, 15 tooth
|
| 10. |
6229256
|
[1] |
SPACER
|
IH
|
| 11. |
766394
|
[1] |
CONSOLE
|
NNA
DRAWBOLT Superseded by part number: 51200285
|
| 12. |
858167
|
[1] |
SPRING
|
L
- extension
|
| 13. |
662958R91
|
[1] |
PULLEY
|
IH
IDLER - flat
|
| 14. |
254409
|
[1] |
SPACER
|
HFI
|
| 15. |
Q81
|
[2] |
KEY,Gib, 3/8" Sq x 1 3/4"
|
IH
3/8 X 1-3/4 KEY - gib
|
| 16. |
7850720
|
[2] |
PINION
|
L
SPROCKET - 60B14 tooth
|
| 17. |
413-1040
|
[1] |
BOLT,Hex, 5/8" - 11 x 2-1/2", Gr 5
|
CAS
Superseded by part number: 280233
|
| 18. |
492-11062
|
[3] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 19. |
425-1010
|
[3] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 20. |
700116045
|
[1] |
LEVER
|
HFI
WA - idler
|
| 21. |
86636814
|
[1] |
LUBE NIPPLE,1/4"-28 x .52" lg
|
GI
NIPPLE, LUBE, 1/4"-28 x .52" lg Superseded by part number: 88775
|
| 22. |
14145H
|
[1] |
CLEVIS PIN,1/2" x 2.094"
|
IH
1/2 X 1-3/4 CLEVIS PIN Superseded by part number: 27-8209
|
| 23. |
51200163
|
[2] |
CLEVIS
|
HFI
|
| 24. |
700116050
|
[1] |
PIVOT ASSY.,25.4 mm OD, 204 mm Length
|
HFI
TUBE - pivot
|
| 25. |
432-1024
|
[1] |
COTTER PIN,5/32" x 1 1/2"
|
CAS
5/32" x 1 1/2" Superseded by part number: 72187233, 88350
|
| 26. |
413-10152
|
[1] |
BOLT,Hex, 5/8" - 11 x 9-1/2", Gr 5
|
CAS
5/8-11 X 9-1/2 B
|
| 27. |
396-21066
|
[1] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 28. |
111-622
|
[1] |
CARRIAGE BOLT,Short NK 5/8" -11 x 2 1/4", G5
|
CAS
5/8-11 X 2-1/4 RHSNB
|
| 29. |
413-840
|
[1] |
BOLT,Hex, 1/2" - 13 x 2-1/2", Gr 5
|
CAS
1/2-13 X 2-1/2 C Superseded by part number: 87972
|
| 30. |
80679
|
[2] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 31. |
425-108
|
[2] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 32. |
6234710
|
[1] |
SPACER
|
CAS
|
| 33. |
413-820
|
[1] |
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 72187215, 87670
|
| 34. |
495-21056
|
[1] |
WASHER,1/2"
|
CAS
1/2 WIDE PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 35. |
432-1016
|
[1] |
COTTER PIN,5/32" x 1"
|
CAS
5/32" x 1" Superseded by part number: 83903970
|
| 36. |
700116051
|
[1] |
PLATE
|
HFI
|
| 37. |
427-8150
|
[1] |
CLEVIS PIN,1/2" x 1 1/2"
|
CAS
1/2X1.500 1.281 HD/HOLE CLEVIS ZND
|
| 38. |
425-116
|
[1] |
NUT,3/8" - 24, Gr 5
|
CAS
Hex 3/8"-24, G5 Superseded by part number: 86509310, 50066
|
| 39. |
700116052
|
[1] |
ROD,THREADED
|
IH
ROD
|
| 40. |
425-106
|
[2] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 41. |
6582696
|
[1] |
SPACER
|
CAS
BUSHING
|
| 42. |
700116039
|
[1] |
SUPPORT
|
CAS
WA (S.N. CFH0016501 thru 0057049)
|
