沃尔沃零件查询AD30A; AQAD30A; MD30A; TAMD30A; TMD30A; AD30; AQAD30; MD30; TAMD30; TMD30TransmissionsPropeller Shaft Stuffing BoxEPC Volvo Penta Parts catalog
广数供应链运营团队, 14 02月, 2025，浏览：
212 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
3819722
|
[1] |
Sealing sleeve, kit
|
For 45mm propeller shaft.
|
| 1. |
3819723
|
[1] |
Sealing sleeve, kit
|
For 50mm propeller shaft.
|
| 1. |
3819724
|
[1] |
Sealing sleeve, kit
|
For 1'' propeller shaft.
|
| 1. |
3819725
|
[1] |
Sealing sleeve, kit
|
For 1 1/4'' propeller shaft.
|
| 1. |
3819726
|
[1] |
Sealing sleeve, kit
|
For 1 1/2'' propeller shaft.
|
| 1. |
3819727
|
[1] |
Sealing sleeve, kit
|
For 1 3/4'' propeller shaft.
|
| 1. |
3819728
|
[1] |
Sealing sleeve, kit
|
For 2'' propeller shaft.
|
| 2. |
|
|
|
|
| 3. |
3818506
|
[1] |
Clamp
|
For 45mm, 50mm, 1 3/4'' and 2'' propeller shaft.
|
| 3. |
828142
|
[1] |
Clamp
|
For 1'' propeller shaft.
|
| 3. |
828418
|
[1] |
Clamp
|
For 1 1/4'' propeller shaft.
|
| 3. |
828528
|
[1] |
Clamp
|
For 1 1/2'' propeller shaft.
|
| 4. |
828250
|
[1] |
Lubricating grease
|
|
| 5. |
|
|
|
|
| 6. |
963684
|
[2] |
Hex. socket screw
|
|
| 7. |
966170
|
[2] |
Lock nut
|
|
