神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (06-005) - EXHAUST BRAKE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
930 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-28. | VAME063719 | [1] | EXHAUST BRAKE ASSY | |
| 1-17. | VAME706595 | [1] | EXHAUST BRAKE VALVE ASSY | |
| 1. | VAME706729 | [1] | BODY | |
| 2. | VAME706730 | [1] | SPINDLE | |
| 3. | VAME706731 | [1] | VALVE | |
| 4. | VAME706732 | [1] | SPINDLE | |
| 5. | VA3093331500 | [1] | BUSHING | |
| 6. | VA3123356200 | [1] | COVER | KOBCOVER Superseded by part number: VA28120513 |
| 7. | VAME706498 | [1] | PLATE,STOPPER | |
| 8. | VAMF450405 | [6] | WASHER | KOBWASHER,SPG 8 Superseded by part number: 132502A1 |
| 9. | VAME706031 | [5] | BOLT | |
| 10. | VA3123356500 | [2] | SCREW | KOBBOLT Superseded by part number: VA11000675 |
| 11. | VAMF430004 | [2] | NUT | KOBNUT Superseded by part number: 132434A1 |
| 12. | VA3123356400 | [1] | LEVER | |
| 13. | VAMF430725 | [1] | NUT | KOBNUT 8 |
| 14. | VA3093331700 | [1] | BUSHING | |
| 15. | VA3123356800 | [1] | GASKET | KOBGASKET Superseded by part number: VA28120900 |
| 16. | VA3093331800 | [2] | SEAL,RING | |
| 17. | VA3093331900 | [2] | SEAL RETAINER | KOBSEAL,RING Superseded by part number: VA13300018 |
| 21. | VAME063715 | [1] | CONTROL CYLINDER ASSY | |
| 22. | VAME063453 | [1] | INSULATOR | |
| 23. | VAMF100095 | [1] | BOLT 10X60 | |
| 24. | VAMC821438 | [2] | NUT | |
| 24. | VAMF450406 | [2] | WASHER | KOBWASHER,SPG 10 |
| 25. | VAME706282 | [2] | WASHER,PLAIN | |
| 26. | VAME706604 | [1] | CLEVIS | |
| 27. | VAME706605 | [1] | PIN | |
| 28. | VAME706285 | [2] | PIN,SNAP | |
| 30. | VAME063680 | [2] | GASKET | KOBGASKET |
