| 1. |
700708340
|
[1] |
GROMMET
|
CAS
|
| 2. |
515-25127
|
[6] |
CLAMP,1/2", Insul, 1/2" Bolt
|
CAS
Line 1/2", Insul, 1/2" Bolt Superseded by part number: 86632595
|
| 3. |
413-620
|
[1] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
C Hex, 3/8"-16 x 1 1/4", G5, Full Thd Superseded by part number: 72187207, 88011
|
| 4. |
232-5316
|
[1] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 5. |
700120657
|
[1] |
ORNAMENTAL STRIP
|
HFI
GROMMET
|
| 6. |
172463
|
[1] |
SELF-TAP SCREW,Hex Hd, 5/16" x 1"
|
CAS
5/16-18 X 3/4 HWHTCTS
|
| 7. |
121-108
|
[3] |
BOLT,Hex Flg, 5/16"-18 x 1 1/4", Serr
|
CAS
5/16-18 X 1 HWHMS
|
| 8. |
231-5145
|
[11] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 9. |
7827983
|
[3] |
GROMMET
|
CAS
|
| 10. |
702700045
|
[2] |
LOCK NUT
|
L
- spiralock
|
| 11. |
700116156
|
[2] |
CRANK
|
CAS
WA
|
| 12. |
515-2295
|
[4] |
CLAMP,3/8", Insul, 5/16" Bolt
|
CAS
Superseded by part number: 86637978
|
| 13. |
121-115
|
[8] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 14. |
232-5315
|
[4] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 15. |
705541
|
[6] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 16. |
700705612
|
[2] |
CAM FOLLOWER
|
L
BEARING - cam Superseded by part number: 86536275
|
| 17. |
51200165
|
[4] |
SCREW,Hex, 1/4"-20 x 1", G5
|
HFI
1/4-20 X 1 C
|
| 18. |
230-4214
|
[4] |
LOCK NUT,1/4"-20, GA
|
CAS
1/4-20 HCLN GR/B Superseded by part number: 87034810
|
| 19. |
113-250
|
[2] |
BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5, Full Thd
|
CAS
|
| 20. |
425-106
|
[4] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 21. |
700116155
|
[2] |
PLATE
|
HFI
|
| 22. |
8025637
|
[2] |
SWITCH
|
L
|
| 23. |
7058266
|
[2] |
SPRING
|
IH
|
| 24. |
413-580
|
[2] |
BOLT,Hex, 5/16" - 18 x 5", Gr 5
|
CAS
Superseded by part number: 88575
|
| 25. |
495-61034
|
[4] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
5/16 WIDE PLAIN WASHER
|
| 26. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 27. |
700116140
|
[2] |
SUPPORT
|
HFI
WA
|
| 28. |
52183
|
[2] |
BUSHING
|
CAS
3/4 X 18 GAUGE NRMB Superseded by part number: Z52183
|
