现代零件查询R140W-7 AIRCON & HEATER MOUNTING(AUTO)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
801 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
AIRCON & HEATER MTG
|
|
| 1. |
11N6-90420
|
[1] |
AIR CON UNIT
|
|
| 2. |
11N6-90430
|
[1] |
CONTROL ASSY-FATC
|
|
| 2. |
11N6-90431
|
[1] |
CONTROL ASSY-FATC
|
|
| 3. |
11N4-90100
|
[1] |
HOSE-SUCTION
|
|
| 3. |
11N4-90101
|
[1] |
HOSE-SUCTION
|
|
| 3-1. |
A304000401-4
|
[1] |
CHARGE VALVE ASSY
|
|
| 3-2. |
A310069299-2
|
[1] |
O-RING
|
|
| 3-3. |
A305000203-2
|
[1] |
O-RING
|
|
| 4. |
11N4-90090
|
[1] |
HOSE(B)-LIQUID
|
|
| 4-1. |
A305000209-2
|
[2] |
O-RING
|
|
| 5. |
11E6-92080
|
[1] |
HOSE
|
|
| 6. |
11E6-92070
|
[1] |
HOSE-DRAIN
|
|
| 7. |
S017-120256
|
[4] |
BOLT-HEX
|
|
| 8. |
S201-061002
|
[1] |
NUT-HEX
|
|
| 9. |
S411-060002
|
[1] |
WASHER-SPRING
|
|
| 10. |
S403-061002
|
[1] |
WASHER-PLAIN
|
|
| 11. |
S201-081002
|
[1] |
NUT-HEX
|
|
| 12. |
S411-080002
|
[1] |
WASHER-SPRING
|
|
| 13. |
S403-081002
|
[1] |
WASHER-PLAIN
|
|
| 14. |
S175-050206
|
[4] |
SCREW-SOCKET RD HD
|
|
| 15. |
S403-052006
|
[4] |
WASHER-PLAIN
|
|
| 16. |
11EK-92090
|
[1] |
HOSE-DRAIN
|
|
| 17. |
S520-020000
|
[1] |
CLAMP-HOSE
|
|
| 18. |
S572-220006
|
[2] |
CLAMP-HOSE,WIRE TYPE
|
|
| 19. |
S441-120006
|
[4] |
WASHER-HARDENED
|
|
| 20. |
73NB-56400
|
[4] |
SHIM
|
|
| 21. |
S152-040122
|
[4] |
SCREW-TAPPING
|
|
| 31. |
11N6-90040
|
[1] |
COMPRESSOR ASSY
|
|
| 31. |
11Q6-90040
|
[1] |
COMPRESSOR ASSY
|
|
| 32. |
11N6-90060
|
[1] |
DRIER-RECEIVER
|
|
| 33. |
11N6-90070
|
[1] |
HOSE-DISCHARGE
|
|
| 33. |
11N6-90191
|
[1] |
HOSE-DISCHARGE
|
|
| 33-1. |
A304000301-4
|
[1] |
CHARGE VALVE ASSY
|
|
| 33-2. |
A305000206-2
|
[1] |
O-RING
|
|
| 33-3. |
A305000205-2
|
[1] |
O-RING
|
|
| 34. |
11NA-90220
|
[1] |
HOSE(A)-LIQUID
|
|
| 34-1. |
A305000209-2
|
[2] |
O-RING
|
|
| 35. |
11N6-90110
|
[1] |
PULLEY-IDLE
|
|
| 35-1. |
A4760-508-00-2
|
[1] |
BRACKET-PULLEY
|
|
| 35-2. |
A4700-511-01-2
|
[1] |
PULLEY-IDLE
|
|
| 35-3. |
A8900-518-03-3
|
[1] |
BOLT-TENSION
|
|
| 36. |
11N8-00130
|
[1] |
V-BELT
|
|
| 37. |
11N6-90340
|
[1] |
FILTER-REC
|
|
| 38. |
11L7-90150
|
[2] |
VALVE-HEATER
|
|
| 40. |
S109-080956
|
[4] |
BOLT-SOCKET
|
|
| 40. |
S109-080856
|
[4] |
BOLT-SOCKET
|
|
| 41. |
S403-081006
|
[4] |
WASHER-PLAIN
|
|
| 42. |
S411-080006
|
[4] |
WASHER-SPRING
|
|
| 43. |
S035-061522
|
[2] |
BOLT-W/WASHER
|
|
| 45. |
S035-083522
|
[2] |
BOLT-W/WASHER
|
|
| 46. |
S205-062002
|
[2] |
NUT-HEX
|
|
| 47. |
S411-060002
|
[2] |
WASHER-SPRING
|
|
| 48. |
S403-062002
|
[2] |
WASHER-PLAIN
|
|
| 49. |
S037-102022
|
[3] |
BOLT-W/WASHER
|
|
| 50. |
S091-060156
|
[3] |
BOLT-WING
|
|
| 51. |
S403-061006
|
[3] |
WASHER-PLAIN
|
|
| 52. |
S572-220006
|
[2] |
CLAMP-HOSE,WIRE TYPE
|
|
| 55. |
11N6-90120
|
[1] |
BRACKET-R/DRIER
|
|
| 56. |
S018-100356
|
[1] |
BOLT-HEX
|
|
| 57. |
S411-100006
|
[1] |
WASHER-SPRING
|
|
| 58. |
S403-10200B
|
[1] |
WASHER-PLAIN
|
|
