纽荷兰零件查询(F4HFA613F E005) - ENGINE - 5801550460 - 84316932 (7/13-) (55.010.AA) - ENGINE, CABLE New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
826 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2854598 | [1] | WIRE HARNESS | TOR Superseded by part number: |
| 2. | 2854599 | [1] | BRACKET | TORM6, D = 16 mm Superseded by part number: 504076667 |
| 3. | 2854600 | [2] | SCREW | TOR20 mm Superseded by part number: 16978124 |
| 4. | 2852484 | [3] | FLANGE NUT | TORM6, D = 26 mm Superseded by part number: 17044625 |
| 5. | 2852500 | [2] | CLAMP | TORM6 x 1 Superseded by part number: |
| 6. | 4899815 | [1] | CLAMP | TORM8, D = 12 mm Superseded by part number: 17315390 |
| 7. | 47401109 | [3] | WIRE HARNESS | BRR |
| 8. | 2852776 | [3] | WASHER | TORM6 x 11 x 1.6 Superseded by part number: 4895421 |
| 9. | 2852602 | [3] | HEX SOC SCREW,M6 x 16mm | SMM6 x 1 x 16 Superseded by part number: 16689121 |
