凯斯零件查询(8460) - CASE IH ROUND BALER (S/N CFH0057418 & AFTER) (1/88-12/93) (4-12) - CONTROL BOX ASSEMBLY, ELECTRICAL, 700710915 CONTROL BOX COMPLETE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
809 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700710915
|
[1] |
CONTROL
|
HFI
BOX COMPLETE
|
| 1. |
700708675
|
[1] |
HARNESS
|
CAS
|
| 2. |
700709892
|
[1] |
BOARD
|
CAS
- PC
|
| 3. |
700708674
|
[1] |
HARNESS
|
CAS
|
| 4. |
700710938
|
[1] |
HARNESS
|
CAS
|
| 5. |
700708673
|
[1] |
HARNESS
|
CAS
- power
|
| 6. |
700707393
|
[1] |
SWITCH
|
HFI
- breaker
|
| 7. |
8021198
|
[3] |
LAMP
|
CAS
|
| 8. |
700708671
|
[1] |
HARNESS
|
CAS
ASSEMBLY (S.N. CFH0016501 thru CFH0016838)
|
| . . |
700712403
|
[1] |
HARNESS
|
CAS
ASSEMBLY (S.N. CFH0016839 and later)
|
| 9. |
440-1066
|
[4] |
SCREW,Cross Pan Hd, #6-32 x 3/8"
|
CAS
#6-32 X 3/8 CRPHMS
|
| 10. |
492-11006
|
[4] |
LOCK WASHER,#6
|
CAS
Washer, Lock, #6 Superseded by part number: 87276
|
| 11. |
225-14106
|
[4] |
NUT,#6-32
|
CAS
Superseded by part number: 88458, 87779111
|
| 12. |
182-5
|
[4] |
SCREW,Sl Pan Hd, #4 - 40 x 3/8"
|
CAS
|
| 13. |
492-11004
|
[4] |
LOCK WASHER,#4
|
CAS
Washer, Lock, #4 Superseded by part number: 84877
|
| 14. |
225-14104
|
[4] |
NUT,#4-40
|
CAS
Superseded by part number: 280385
|
| 15. |
700708672
|
[1] |
HARNESS
|
CAS
- power (S.N. CFH0016501 thru CFH0016838)
|
| . . |
700712423
|
[1] |
HARNESS
|
CAS
- power (S.N. CFH0016839 and later)
|
| 16. |
700704212
|
[2] |
SELF-TAP SCREW
|
CAS
#4-24 X 3/8 SPHTFTS
|
| 17. |
700707458
|
[1] |
INDICATOR
|
IH
LIGHT - green
|
| 18. |
700707459
|
[4] |
INDICATOR
|
IH
LIGHT - amber
|
| 19. |
700708670
|
[2] |
CAP
|
CAS
LENS - red
|
| 20. |
700710925
|
[1] |
CAP
|
CAS
LENS - green
|
| 21. |
281-1478
|
[6] |
SELF-TAP SCREW,1/4" - 20 x 1/2"
|
CAS
1/4-20 X 1/2 HWHTCTS
|
| 22. |
700116147
|
[1] |
COVER
|
HFI
|
| 23. |
A59457
|
[1] |
BRACKET
|
CAS
SOCKET Superseded by part number: 847590
|
| 24. |
1270468C1
|
[2] |
SELF-TAP SCREW,Cross Pan Hd, 5/16" - 18 x 1/2"
|
IH
5/16-18 X 1/2 CRPHMS
|
| 25. |
231-5145
|
[2] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 26. |
700707449
|
[1] |
SWITCH
|
CAS
- toggle
|
| 27. |
700707450
|
[1] |
SWITCH
|
HFI
- toggle
|
| 28. |
700703984
|
[1] |
INDICATOR
|
IH
- audio (Horn)
|
| 29. |
700707452
|
[3] |
SWITCH
|
HFI
- toggle
|
| 30. |
700709399
|
[1] |
SWITCH
|
CAS
- toggle
|
