凯斯零件查询(8460) - CASE IH ROUND BALER (S/N CFH0057418 & AFTER) (1/88-12/93) (7-10) - SHIELDS ASSEMBLY, FRONT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
462 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
74740
|
[5] |
NUT
|
CAS
- speed
|
| 2. |
413-48
|
[5] |
BOLT,Hex, 1/4" - 20 x 1/2", Gr 5
|
CAS
Superseded by part number: 88542
|
| 3. |
700129372
|
[1] |
PLATE
|
HFI
|
| 4. |
700129373
|
[1] |
COVER
|
HFI
|
| 5. |
121-108
|
[2] |
BOLT,Hex Flg, 5/16"-18 x 1 1/4", Serr
|
CAS
5/16-18 X 1 HWHMS
|
| 6. |
231-5145
|
[10] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 7. |
495-61034
|
[3] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
5/16 WIDE PLAIN WASHER
|
| 8. |
121-115
|
[7] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 9. |
700129377
|
[1] |
SHIELD
|
HFI
|
| 10. |
700126761
|
[2] |
SUPPORT
|
CAS
|
| 11. |
440-13112
|
[1] |
SCREW,Cross Pan Hd, 5/16"-18 x 3/4"
|
CAS
5/16-18 X 3/4 CRPHMS GR2 Superseded by part number: 86511938
|
