神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (03-023) - FUEL HOSE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
678 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME910490 | [1] | HOSE,FUEL FEED,PUMP-FILTER- L = 900 | |
| 2. | VAME910470 | [1] | HOSE | KOBHOSE,FUEL FEED,FILTER-PUMP L = 700 |
| 3. | VA3006155500 | [1] | CLIP | KOBCLAMP CLIP Superseded by part number: VAMH020280 |
| 4. | VAMF140234 | [1] | SPECIAL BOLT | KOBBOLT,FLANGE 8X45 |
| 4A. | VAMF140021 | [1] | SCREW | KOBBOLT, FLANGE 8x12 |
| 4A. | VAMF434104 | [1] | NUT | KOBNUT, FLANGE 8 |
| 5. | VAME020729 | [1] | SPACER | KOBSPACER |
