卡特零件查询（725） 184-6138: LINES GP-AIR CONDITIONER
广数供应链运营团队, 14 02月, 2025，浏览：
877 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 103-6100 | [1] | FITTING AS-AIR CONDITIONER(QUICK DISCONNECT) | |
| | 9X-7382 | [2] | SEAL-O-RING | |
| 2. | 184-6139I | [1] | HOSE AS | |
| 3. | 185-6981 | [1] | BRACKET AS | |
| 4. | 186-6189 | [1] | ACCUMULATOR-REFRIGERANT | |
| 5. | 101-8296 | [2] | CLIP | |
| 6. | 109-1633 | [1] | CLIP(SLOT) | |
| 7. | 109-1634 | [1] | CLIP(TAB) | |
| 8. | 116-6202 | [1] | BOOT | |
| 9. | 184-6140I | [1] | HOSE AS | |
| 10. | 175-7162 | [1] | DRYER AS-REFRIGERANT(IN-LINE) | |
| | 7X-2049 | [1] | TUBE AS | |
| | 330-3117 | [1] | FILM-WARNING(UNIVERSAL, READ OMM) | |
| 11. | 8T-4121 | [5] | WASHER-HARD(11X21X2.5-MM THK) | |
| 12. | 8T-4136M | [1] | BOLT(M10X1.5X25-MM) | |
| 13. | 8T-4137M | [4] | BOLT(M10X1.5X20-MM) | |
| 14. | 9X-7380 | [1] | SEAL-O-RING | |
| 15. | 9X-7381 | [1] | SEAL-O-RING | |
| 16. | 9X-7382 | [1] | SEAL-O-RING | |
| 17. | 9X-7383 | [1] | SEAL-O-RING | |
| 18. | 6V-2495D | | SEAL(0.3-M) | |
| | D | | ORDER BY THE METER |
| | I | | REFER TO HYDRAULIC INFORMATION SYSTEM |
| | M | | METRIC PART |
