纽荷兰零件查询(F4HFA613G E001) - ENGINE - 5801550427 - 84316934 (7/13-) (10.218.AI[02]) - INJECTION PIPE New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
920 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2855125 | [1] | TUBE | TOR |
| 2. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 3. | 4894095 | [3] | O-RING,2.5mm Thk x 8mm ID, 60 Duro | TOR |
| 4. | 4896329 | [1] | PRESSURE RELIEF VALVE | TOR |
| 5. | 2852457 | [1] | CLAMP | TOR Superseded by part number: 99481827 |
| 6. | 2852458 | [1] | CLIP | TOR Superseded by part number: 504065285 |
| 7. | 2852100 | [1] | FLANGE BOLT,Hex, M8 x 1.25 x 16mm | TOR Superseded by part number: 16586225 |
