凯斯零件查询(8460) - CASE IH ROUND BALER (S/N CFH0057418 & AFTER) (1/88-12/93) (6-24) - ROLLER ASSEMBLY, FLAP Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
596 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700117115
|
[1] |
ROLLER
|
HFI
WA
|
| 2. |
700707980
|
[4] |
FLAP
|
CAS
- rubber (S.N. CFH0016501 thru CFH0017638)
|
| . . |
700711997
|
[4] |
FLAP
|
CAS
- rubber (S.N. CFH0017639 and later)
|
| 3. |
493-81008
|
[36] |
LOCK WASHER,Int Tooth, 5/16"
|
CAS
WASHER - internal tooth lock, 5/16 inch Superseded by part number: 280542
|
| 4. |
700709140
|
[36] |
SELF-TAP SCREW,Pan HD, 5/16" - 18 x 3/4"
|
IH
5/16-18 X 3/4 CRTHTCTS
|
| 5. |
700117116
|
[4] |
STRAP
|
CAS
|
