神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE - K909LC & MD240BLC (1/87-12/06) (01-018) - CRANKSHAFT & PULLEY P/N ME072238 Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
481 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-3. | VAME072238 | [1] | CRANK SHAFT ASSY, M14 | CRANK SHAFT ASSY, M14 |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONCRANKSHAFT |
| 2. | VAMF472407 | [1] | PIN | KOBPIN, DOWEL 14 |
| 3. | VAMH012026 | [1] | PIN | KOBPIN, DOWEL |
| 5. | VAME032038 | [1] | SLINGER | KOB |
| 6. | VAME032356 | [1] | PULLEY | KOBPCD155 |
| 7. | VAME032158 | [1] | ROCKER ARM COTTER | KOBTAPER |
| 8. | VAMH004052 | [1] | NUT | KOBNUT |
| 9. | VAMF476059 | [1] | KEY | KOBKEY, SUNK, 10 X 20 |
