纽荷兰零件查询(F4HFA613G E001) - ENGINE - 5801550427 - 84316934 (7/13-) (10.400.AE) - ENGINE, COOLING SYSTEM LINE New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
338 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2852286 | [2] | BOLT,Flng, M10 x 1.5 x 130mm | TOR Superseded by part number: 16599125 |
| 2. | 2854072 | [2] | SEALING RING,Square, 5.16mm Thk x 50.17mm ID | TOR Superseded by part number: 504062710 |
| 3. | 2854938 | [1] | FITTING | TORASSY, Incl 2, 4, 5, Alternative Superseded by part number: 504062633 |
| 3. | 4892347 | [1] | SUPPORT | LECASSY, Incl 2, 4, 5, Alternative Superseded by part number: 504062633 |
| 4. | 4895576 | [2] | DOWEL | TOR |
| 5. | NSS | [1] | NOT SERVICED SEPARATELY | CONSupport, Incl in 3 |
| 6. | 4895392 | [2] | HEX SOCKET PLUG,M18 x 1.5 | TORASSY, Incl 7, 8 |
| 7. | 4895393 | [2] | O-RING,2.2mm Thk x 15.3mm ID | TOR |
| 9. | 4895625 | [1] | O-RING,13.3mm ID x 2.2mm Width | TOR Superseded by part number: 17281681 |
| 11. | 4895623 | [1] | HEX SOCKET PLUG,M16 x 1.5 | TORASSY, Incl 9, 10 |
| 12. | 4893036 | [2] | PIPE PLUG,3/4"-14 NPTF | TOR Superseded by part number: 2854866 |
| 14. | 4895080 | [1] | HEX SOCKET PLUG,M22 x 1.5 | TORASSY, Incl 13, 15 |
| 16. | 4895078 | [3] | PIPE PLUG,1/2"-14 | TOR |
| 17. | 4895292 | [1] | FLANGE BOLT,Hex, M10 x 1.5 x 70mm | LEC |
| 18. | 2854491 | [1] | PLUG,Taper Pipe, Hex, 1/4" - 18 x 14.224mm | TOR |
