凯斯零件查询(8460) - MESH WRAP KIT AND MESH WRAP ADAPTER KIT (1/88-12/94) (12) - MESH WRAP BOX AND ROLLER DRIVE ASSEMBLIES, MESH WRAP KIT HK50598, COMPLETE, INCLUDES PGS 21 THRU 33 Case Agriculture_凯斯Case_工程机械

凯斯零件查询(8460) - MESH WRAP KIT AND MESH WRAP ADAPTER KIT (1/88-12/94) (12) - MESH WRAP BOX AND ROLLER DRIVE ASSEMBLIES, MESH WRAP KIT HK50598, COMPLETE, INCLUDES PGS 21 THRU 33 Case Agriculture

广数供应链运营团队, 14 02月, 2025，浏览： 580 次

Pos.	Part No	Qty	Parts name	Comments
1.	7883325	[4]	BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M	CAS 5/16-18 X 3/4 HWHMS Superseded by part number: 121-115
2.	704239	[4]	FRONT AXLE	NNA 5/16-18 HFSLN GR/F Superseded by part number: 231-5145, 231-5145, NLS
3.	700125752	[1]	HINGE	HFI WA-LEFT
4.	700125756	[1]	ADAPTER	HFI WA-LEFT
5.	700710874	[3]	CYLINDER	CAS -HYDRAULIC
6.	700125750	[2]	LATCH	HFI WA
7.	703512	[3]	BOLT,Hex, 1/2" - 13 x 2 1/4", Gr 5	CAS 1/2-13 X 2-1/4 C Superseded by part number: 413-836, 413-836, 70924864
8.	86516876	[7]	1/2-13 H	COVER
9.	62083	[7]	PIN	CAS 1/8 X 1 COTTER PIN Superseded by part number: 432-816, 432-816, NLS
10.	705541	[5]	WASHER,0.53" ID x 1.06" OD x 0.14" Thk	CAS 1/2 HARDENED PLAIN WASHER
11.	61622	[2]	BUCKET TOOTH KEY	IH 1/4 X 1-1/2 GIB KEY Superseded by part number: Q3914
12.	700125843	[1]	SHEAVE	CAS
13.	54833	[1]	FRONT IDLER	CAS IDLER-V
14.	700125855	[1]	GUIDE	HFI -BELT
15.	700125912	[2]	PLATE	HFI
16.	7700248	[1]	CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 2", Gr 5	CAS 1/2-13 X 2 RHSNB Superseded by part number: 280185
17.	80679	[1]	LOCK WASHER,1/20.507 CST ZND	NH WASHER, LOCK, 1/2"
18.	700125796	[1]	SUPPORT	HFI WA
19.	703249	[4]	BOLT,Hex, 3/8" - 16 x 1", Gr 5	CAS 3/8-16 x 1 C Superseded by part number: 88206
20.	705038	[8]	CONTROL VALVE	CAS 3/8" Superseded by part number: 492-11038
21.	704023	[8]	NUT,3/8"-16, G5	CAS 3/8-16 H Superseded by part number: 280136
22.	700125830	[1]	DRUM	CAS -BRAKE
23.	NLS	[4]	NO LONGER SERVICED	BAS 5/8 HARDENED PLAIN WASHER
24.	700710931	[2]	BUSHING	CAS
25.	705533	[2]	WASHER	NNA 3/8 HARDENED PLAIN WASHER Superseded by part number: 496-11041, 496-11041, 80702
26.	700710941	[3]	SEAL KIT	CAS KIT-SEAL
27.	700125759	[1]	ADAPTER	HFI WA-RIGHT
28.	700125915	[2]	SPRING	HFI -TORSION
29.	700125760	[4]	WEDGE	CAS
30.	700125755	[1]	HINGE	HFI WA-RIGHT
31.	705012	[4]	LOCK WASHER	CAS 1/4" Superseded by part number: 492-11025, 492-11025, 86517257
32.	704007	[4]	NUT,1/4"-20, G5	CAS 1/4-20 H Superseded by part number: 7770
33.	700047	[4]	BOLT	CAS 3/8-16 X 1 RHSNB Superseded by part number: 80280503
34.	700125717	[1]	SHIELD	HFI
