凯斯零件查询(8460) - MESH WRAP KIT AND MESH WRAP ADAPTER KIT (1/88-12/94) (16) - MESH WRAP ROLLER ASSEMBLY, SERIAL NUMBER CFH0073001 THROUGH 0073010 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
658 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700125703
|
[1] |
PANEL
|
HFI
WA-LEFT Superseded by part number: 700124962
|
| 2. |
700125821
|
[1] |
SUPPORT
|
HFI
WA-LEFT
|
| 3. |
703249
|
[12] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 x 1 C Superseded by part number: 88206
|
| 4. |
705038
|
[12] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
| 5. |
704023
|
[12] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| 6. |
700125812
|
[1] |
BUMPER
|
HFI
|
| 7. |
700013
|
[11] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 X 3/4 RHSNB
|
| 8. |
705020
|
[13] |
LOCK WASHER
|
CAS
5/16" Superseded by part number: 492-11031, 492-11031, NLS
|
| 9. |
704015
|
[11] |
NUT,5/16"-18, G5
|
CAS
5/16-18 H Superseded by part number: 425-105, 425-105, 9635082
|
| 10. |
705525
|
[18] |
WASHER
|
CAS
5/16 HARDENED PLAIN WASHER Superseded by part number: 86637953
|
| 11. |
7758915
|
[2] |
SPRING
|
CAS
|
| 12. |
700125816
|
[1] |
FLAP
|
HFI
|
| 13. |
700125817
|
[1] |
SUPPORT
|
HFI
WA
|
| 14. |
7701519
|
[2] |
SCREW,5/16" - 18 x 1"
|
CAS
5/16-18 X 1 HWHTCTS Superseded by part number: 281-14816
|
| 15. |
7770142
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 1/4" - 20 x 1/2", Gr 5
|
CAS
1/4-20 X 1/2 RHSNB Superseded by part number: 280700
|
| 16. |
523282
|
[2] |
SERRATED NUT,Flg, USR, 1/4"-20
|
WIN
1/4-20 HFSLN GR/F
|
| 17. |
700125911
|
[1] |
MOUNTING PARTS
|
HFI
MOUNT-MAGNET
|
| 18. |
700710211
|
[1] |
ACTUATOR
|
IH
|
| 19. |
700125814
|
[1] |
SUPPORT
|
HFI
Superseded by part number: 700124969
|
| 20. |
701953
|
[7] |
SELF-TAP SCREW
|
CAS
5/16-18 X 3/4 HWHTTS Superseded by part number: 172463
|
| 21. |
700709141
|
[7] |
LOCK WASHER
|
CAS
51/6 ITLW Superseded by part number: 280542
|
| 22. |
700125819
|
[1] |
SUPPORT
|
HFI
WA-RIGHT
|
| 23. |
700126767
|
[1] |
REINFORCEMENT
|
HFI
|
| 24. |
700125809
|
[1] |
KNIFE
|
HFI
WA Superseded by part number: 700124960
|
| 25. |
700125813
|
[1] |
SUPPORT
|
HFI
|
| 26. |
700125825
|
[1] |
SUPPORT
|
HFI
WA-RIGHT
|
| 27. |
700125713
|
[1] |
PANEL
|
HFI
WA-RIGHT Superseded by part number: 700124963
|
| 28. |
700125694
|
[1] |
ROLLER
|
HFI
WA
|
| 29. |
700125700
|
[1] |
ROLLER
|
HFI
|
| 30. |
51680
|
[2] |
BEARING, BALL
|
CAS
BEARING Superseded by part number: 47577183, 45396
|
| 31. |
700125820
|
[1] |
SHAFT
|
HFI
|
