卡特零件查询（725） 234-5593: LINES GP-SERVICE BRAKE

广数供应链运营团队, 14 02月, 2025，浏览： 411 次

Pos.	Part No	Qty	Parts name
1.	6U-0456	[3]	STRAP
2.	144-8064I	[1]	HOSE AS
3.	145-6130I	[1]	HOSE AS
4.	170-1469I	[1]	HOSE AS
5.	179-9407I	[1]	HOSE AS
6.	179-9416	[1]	TUBE AS
7.	188-9629	[1]	BRACKET
8.	201-4032I	[1]	HOSE AS
9.	243-2136I	[1]	HOSE AS
10.	243-2601	[1]	TUBE AS
11.	243-2602	[1]	TUBE AS
12.	249-5451	[1]	BRACKET
13.	249-5452	[1]	TUBE AS
14.	250-1810I	[2]	HOSE AS
15.	250-1811I	[2]	HOSE AS
16.	148-8336	[2]	CONNECTOR AS
			(EACH INCLUDES)
	3J-1907	[1]	SEAL-O-RING
	6V-8397	[1]	SEAL-O-RING
	6V-8636	[1]	CONNECTOR
17.	148-8340	[1]	CONNECTOR AS
	3K-0360	[1]	SEAL-O-RING
	6V-8398	[1]	SEAL-O-RING
	6V-8639	[1]	CONNECTOR
18.	148-8364	[1]	ELBOW AS
	3K-0360	[1]	SEAL-O-RING
	6V-8398	[1]	SEAL-O-RING
	6V-8625	[1]	ELBOW
19.	148-8366	[2]	ELBOW AS
			(EACH INCLUDES)
	6V-8397	[2]	SEAL-O-RING
	6V-8987	[1]	ELBOW
20.	148-8370	[1]	ELBOW AS
	6V-8398	[1]	SEAL-O-RING
	6V-9851	[1]	ELBOW
21.	148-8415	[3]	REDUCER AS
			(EACH INCLUDES)
	6V-8397	[1]	SEAL-O-RING
	6V-8936	[1]	REDUCER
22.	148-8427	[1]	TEE AS
	6V-8398	[3]	SEAL-O-RING
	8T-6895	[1]	TEE-UNION
23.	148-8444	[1]	TEE AS-SWIVEL
	6V-8398	[2]	SEAL-O-RING
	6V-9837	[1]	TEE-SWIVEL
24.	148-8457	[3]	UNION AS(STRAIGHT)
			(EACH INCLUDES)
	6V-8398	[2]	SEAL-O-RING
	6V-8995	[1]	UNION(STRAIGHT)
25.	149-5452	[2]	UNION AS(STRAIGHT)
			(EACH INCLUDES)
	6V-8397	[2]	SEAL-O-RING
	6V-8994	[1]	UNION(STRAIGHT)
26.	6V-9168	[4]	NUT(11/16-16-THD)
27.	6V-9169	[4]	NUT(13/16-16-THD)
28.	8T-4121	[2]	WASHER-HARD(11X21X2.5-MM THK)
29.	8T-4123	[6]	WASHER(3.62X5.75X0.375-MM THK)
30.	8T-4137M	[2]	BOLT(M10X1.5X20-MM)
31.	8T-4139M	[1]	BOLT(M12X1.75X30-MM)
32.	8T-4223	[1]	WASHER-HARD(13.5X25.5X3-MM THK)
33.	9X-8257	[2]	WASHER(17.5X30X3.5-MM THK)
	I		REFER TO HYDRAULIC INFORMATION SYSTEM
	M		METRIC PART
