| 1. |
700124566
|
[1] |
SHIELD
|
HFI
WA-LEFT
|
| 2. |
700711948
|
[2] |
SPRING
|
CAS
-TORSION
|
| 3. |
700711189
|
[1] |
DECAL
|
CAS
-NET-TWINE
|
| 4. |
700125718
|
[1] |
SHIELD
|
HFI
|
| 5. |
700125893
|
[1] |
PLATE
|
HFI
|
| 6. |
7701485
|
[2] |
BOLT,Hex, 1/4" - 20 x 2", Gr 5
|
CAS
1/4-20 X 2 C Superseded by part number: 87404
|
| 7. |
523282
|
[8] |
SERRATED NUT,Flg, USR, 1/4"-20
|
WIN
1/4-20 HFSLN GR/F
|
| 8. |
7883374
|
[10] |
SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 255918
|
| 9. |
704247
|
[20] |
NUT
|
CAS
3/8-16 HFSLN GR/F Superseded by part number: 231-5146, 231-5146, 280736, 231-5146, 280736, 692965, 231-5146, 280736, 692965, 87362
|
| 10. |
700711334
|
[6] |
FASTENER
|
CAS
-PUSH ON
|
| 11. |
7883325
|
[14] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 X 3/4 HWHMS Superseded by part number: 121-115
|
| 12. |
704239
|
[14] |
FRONT AXLE
|
NNA
5/16-18 HFSLN GR/F Superseded by part number: 231-5145, 231-5145, NLS
|
| 13. |
700125719
|
[1] |
SHIELD
|
HFI
|
| 14. |
727248
|
[1] |
GROMMET
|
CAS
-RUBBER
|
| 15. |
700124567
|
[1] |
SHIELD
|
CAS
WA-RIGHT
|
| 16. |
700124553
|
[2] |
PLATE
|
HFI
HOLDDOWN
|
| 17. |
432-68
|
[2] |
COTTER PIN,3/32" x 1/2"
|
CAS
3/32 X 1/2 COTTER PIN Superseded by part number: 88788
|
| 18. |
700125844
|
[2] |
SLEEVE
|
CAS
SUPPORT Superseded by part number: 700136023
|
| 19. |
776682
|
[2] |
HOOK
|
CAS
-RUBBER Superseded by part number: 86975220
|
| 20. |
776674
|
[2] |
SUPPORT
|
L
ANCHOR
|
| 21. |
700124551
|
[6] |
HINGE
|
CAS
-SUPPORT
|
| 22. |
700711083
|
[1] |
HARNESS
|
CAS
-WIRE
|
| 23. |
63784
|
[2] |
CLEVIS PIN
|
IH
1/4 X 1-1/2 CLEVIS PIN Superseded by part number: 141-13
|
| 24. |
7025075
|
[2] |
BRACKET
|
CAS
|
| 25. |
878660
|
[2] |
REFLECTOR
|
IH
-RED
|
| 26. |
700711322
|
[2] |
DECAL
|
CAS
-CAUTION
|
| 27. |
700706191
|
[2] |
DECAL
|
CAS
-WARNING, INJURY
|
| 28. |
311858A1
|
[1] |
DECAL
|
CAS
EMBLEM-SMV Superseded by part number: 86547711
|
| 29. |
700711130
|
[1] |
DECAL
|
CAS
-NOTICE
|
| 30. |
700711129
|
[1] |
DECAL
|
CAS
-OPERATIONAL
|
| 31. |
700054
|
[6] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
3/8-16 X 1-1/4 RHSNB Superseded by part number: 86508773
|
| 32. |
700704837
|
[4] |
SCREW,Cross Pan Hd, #10-24 x 3/8"
|
CAS
#10-24 X 3/8 CRPHMS GR2 Superseded by part number: 72181877
|
| 33. |
705004
|
[4] |
LOCK WASHER
|
CAS
#10 L Superseded by part number: 80684
|
| 34. |
NLS
|
[4] |
NO LONGER SERVICED
|
BAS
10-24 H GR2
|
| 35. |
700710930
|
[2] |
PAD
|
CAS
|
| 36. |
700711167
|
[4] |
SCREW
|
CAS
1/4-20 X 3/4 CRPHMS Superseded by part number: 86511932
|
| 37. |
700047
|
[4] |
BOLT
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
