神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE - K909LC & MD240BLC (1/87-12/06) (01-042) - OIL FILLER & OIL LEVEL GAUGE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
980 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME064440 | [1] | GAUGE | KOBCAGE LEVEL |
| 2. | VAME070798 | [1] | OPERATING CYLINDER LEVEL | OPERATING CYLINDER LEVEL |
| 3. | VAMF520007 | [1] | O-RING | KOBO-RING 11 |
| 5. | VAMH035230 | [1] | O-RING | KOBO-RING 10 |
| 6. | VAME930068 | [1] | STAY, OIL LEVEL GAUGE | |
| 7. | VAMB050032 | [1] | CLAMP | |
| 8. | VAMF140003 | [1] | BOLT | KOBBOLT, FLANGE, 6 X 12 |
| 9. | VAMH000399 | [1] | SCREW | KOBBOLT, 8 X 16 |
| 9A. | VAME920031 | [1] | SPACER, L=28 | |
| 9B. | VAMF140234 | [1] | SPECIAL BOLT | KOBBOLT, FLANGE, 8 X 45 |
| 20. | VAMH037755 | [1] | CAP, SEALING 13 | |
