| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 4E-9452 | [6] | PLUG | |
| 2. | 193-2113 | [2] | CAP-END | |
| 3. | 175-3587 | [4] | BUSHING AS | |
| 4. | 195-5789C | [4] | MOUNT AS | |
| 5. | 219-7364 | [2] | ARM AS | |
| 6. | 8T-4132M | [16] | NUT(M16X2-THD) | |
| 7. | 8T-4140M | [16] | BOLT(M16X2X60-MM) | |
| 8. | 6V-8237 | [6] | WASHER(26X44X4-MM THK) | |
| 9. | 6V-8133M | [6] | BOLT(M24X3X80-MM) | |
| 10. | 9X-8257 | [32] | WASHER(17.5X30X3.5-MM THK) | |
| C | CHANGE FROM PREVIOUS TYPE | |||
| M | METRIC PART | |||
