纽荷兰零件查询(F4HFE6132 A003) - ENGINE 5801753676 - 47541755 (1/14-) (10.414.AC) - FAN New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
420 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4890732 | [1] | RETAINER,11.50mm ID x 52mm OD x 7mm | TOR |
| 2. | 2853210 | [1] | BRACKET | TORASSY, Incl 1, 3, 5 - 8 |
| 3. | NSS | [1] | NOT SERVICED SEPARATELY | CONSupport, Incl in 2 |
| 4. | 4899053 | [4] | SCREW,Hex Flg, M8 x 45 | TOR |
| 5. | 2852171 | [1] | SNAP RING | TOR Superseded by part number: 32324 |
| 6. | 4892426 | [1] | HUB | TOR |
| 7. | 4892732 | [1] | BALL BEARING,34mm ID x 64mm OD x 37mm W | TOR |
| 8. | 2852172 | [1] | BOLT,Flng, M10 x 1.5 x 70mm | TORM10 x 70 Superseded by part number: 16676834 |
