神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE - K909LC & MD240BLC (1/87-12/06) (05-003) - EMERGENCY PARTS Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
838 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME049145 | [1] | SOLENOID | KOBSTOP, 24V ND |
| 2. | VAMF140221 | [4] | BOLT | KOBFLANGE, 8 X 12 |
| 3. | VAME032806 | [1] | BRACKET, SOLENOID | |
| 4. | VAMF300841 | [4] | SCREW | KOBW/WSR, 10 X 20 Superseded by part number: 132461A1 |
| 5-8. | VAME008584 | [1] | ROD ASSY, L=213 | |
| 5. | VAME008585 | [1] | ROD | |
| 6. | VAMF430003 | [1] | NUT | KOB5 Superseded by part number: 135143A1 |
| 6A. | VAMH004030 | [1] | NUT, LH SCREW 5 | |
| 7. | VAME023500 | [1] | JOINT, BALL | |
| 7A. | VAME023501 | [1] | JOINT, BALL LH SCREW | |
| 8. | VAMF430003 | [2] | NUT | KOB5 Superseded by part number: 135143A1 |
| . . | VAMF450403 | [2] | WASHER SPG 5 | WASHER SPG 5 |
| 8A. | VAMF450003 | [2] | WASHER PLAIN 5 | WASHER PLAIN 5 |
| 13A. | VAMH021013 | [1] | CLAMP | CLAMP |
| 20. | VAMS616003 | [1] | PIPE, VINYL, L=400 | |
| 21. | VAMH021104 | [1] | CLAMP, HOSE | |
