现代零件查询R140W-7 TOOL BOX MOUNTINGEPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
580 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 2. |
71N4-42400
|
[1] |
PIPE WA
|
|
| 2. |
71N4-42400BG
|
[1] |
PIPE WA
|
|
| 3. |
71N4-42500
|
[1] |
PIPE WA
|
|
| 3. |
71N4-42500BG
|
[1] |
PIPE WA
|
|
| 4. |
71N8-46000
|
[1] |
MIRROR
|
|
| 4. |
71N8-47100
|
[1] |
MIRROR
|
|
| 4. |
71N8-47101
|
[1] |
MIRROR
|
|
| 5. |
71E4-3004
|
[1] |
MIRROR
|
|
| 5. |
71N4-46100
|
[1] |
MIRROR
|
|
| 6. |
71N4-42601
|
[1] |
STAY-MIRROR
|
|
| 6. |
71N4-42900
|
[1] |
STAY WA-MIRROR
|
|
| 6. |
71N4-42900BG
|
[1] |
STAY WA-MIRROR
|
|
| 7. |
71N4-42700
|
[1] |
PIN-SWING LOCK
|
|
| 8. |
71N4-42800
|
[1] |
CLAMP ASSY-SW LOCK PIN
|
|
| 9. |
S390-015040
|
[4] |
SHIM-ROUND(0.5T)
|
|
| 11. |
S037-122552
|
[16] |
BOLT-W/WASHER
|
|
| 12. |
S037-102552
|
[3] |
BOLT-W/WASHER
|
|
| 13. |
71N4-44100
|
[1] |
COVER-F/TANK
|
|
| 14. |
71W1-54020
|
[1] |
CHAIN ASSY
|
|
| 15. |
74N4-47100
|
[1] |
FOOT BOARD WA(A)
|
|
| 16. |
74N4-47200
|
[1] |
FOOT BOARD WA(C)
|
|
| 16. |
74N4-47200BG
|
[1] |
FOOT BOARD WA(C)
|
|
| 17. |
S037-121552
|
[8] |
BOLT-W/WASHER
|
|
| 3. |
71N8-46000
|
[1] |
MIRROR
|
|
| 3. |
71N6-47000
|
[1] |
MIRROR & STAY ASSY-LH
|
|
| 3. |
71N6-47000BG
|
[1] |
MIRROR & STAY ASSY-LH
|
|
| 3. |
71N6-47001BG
|
[1] |
MIRROR & STAY ASSY-LH
|
|
| 3. |
71N6-47000BG
|
[1] |
MIRROR & STAY ASSY-LH
|
|
| 3. |
71N6-47001BG
|
[1] |
MIRROR & STAY ASSY-LH
|
|
| 4. |
71E1-60340
|
[1] |
HAMMER-SAFETY
|
|
| 5. |
S141-040166
|
[2] |
SCREW-FLAT HD
|
|
| 6. |
S017-120706
|
[8] |
BOLT-HEX
|
|
| 7. |
S037-122526
|
[1] |
BOLT-W/WASHER
|
|
| 8. |
S403-122006
|
[8] |
WASHER-PLAIN
|
|
| 9. |
S411-120006
|
[8] |
WASHER-SPRING
|
|
| 10. |
S411-100006
|
[4] |
WASHER-SPRING
|
|
| 11. |
S403-102006
|
[4] |
WASHER-PLAIN
|
|
| 12. |
S017-100256
|
[4] |
BOLT-HEX
|
|
| 13. |
71N6-03560
|
[1] |
RAIL-HAND
|
|
| N14. |
71N6-10270
|
[1] |
PLATE
|
|
| 15. |
S131-051546
|
[2] |
SCREW-W/WASHER
|
|
| 16. |
71N6-03632
|
[1] |
SUN VISOR ASSY
|
|
| 16-1. |
S132-060856
|
[4] |
SCREW-W/WASHER
|
|
