凯斯零件查询(8465) - CASE IH AUTO ROUND BALER (1/91-12/97) (2-14) - CLUTCH CONTROL ASSEMBLY, DRIVE SHAFT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
450 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700116072
|
[8] |
SHIM
|
CAS
|
| 2. |
700116071
|
[3] |
SPACER
|
HFI
|
| 3. |
413-672
|
[3] |
BOLT,Hex, 3/8" - 16 x 4-1/2", Gr 5
|
CAS
3/8-16 X 4-1/2 C Superseded by part number: 86505980
|
| 4. |
496-11041
|
[6] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 5. |
492-11038
|
[7] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 6. |
425-106
|
[7] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 7. |
113-252
|
[2] |
BOLT,Hex, 3/8" - 16 x 3-3/4", Gr 5
|
CAS
Superseded by part number: 86505979
|
| 8. |
700116070
|
[4] |
SPACER
|
CAS
|
| 9. |
413-652
|
[2] |
BOLT,Hex, 3/8" - 16 x 3-1/4", Gr 5
|
CAS
Superseded by part number: 9637240
|
| 10. |
700116065
|
[4] |
SPACER
|
HFI
|
| 11. |
D38346
|
[4] |
BALL BEARING,10 mm ID x 30 mm OD x 9 mm
|
CAS
BEARING - cylindrical Superseded by part number: 9847562
|
| 12. |
100-21118
|
[4] |
SNAP RING,1.188", Int, #118
|
CAS
Ring, Snap, 1.188", Int, #118 Superseded by part number: 129738
|
| 13. |
700127887
|
[4] |
ARM
|
HFI
- clutch
|
| 14. |
700126815
|
[4] |
ROLLER
|
CAS
ASSEMBLY (Includes items 11 and 12)
|
| 15. |
700116069
|
[1] |
SPACER
|
HFI
|
