凯斯零件查询(8465) - CASE IH AUTO ROUND BALER (1/91-12/97) (2-22) - ROLLER DRIVE ASSEMBLY, STARTING Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
733 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
433-1064
|
[1] |
CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 4", Gr 5
|
CAS
5/8-11 X 4 RHSNB Superseded by part number: 280461
|
| 2. |
492-11062
|
[1] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 3. |
425-1010
|
[1] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 4. |
6867667
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET WA - 60B23 tooth
|
| 5. |
6621155
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET WA - 60B19 tooth (Without mesh wrap only)
|
| . . |
700124968
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET WA - 60B24 tooth (Comes with mesh wrap kit only)
|
| 6. |
Q3947
|
[2] |
KEY,Gib, 3/8" Sq x 1 1/2"
|
IH
3/8 X 1-1/2 KEY - gib
|
| 7. |
7086002
|
[1] |
CHAIN (AG)
|
CAS
CHAIN - roller, #60 (10 foot bulk) Superseded by part number: 611362R91X, 241-1316
|
| 8. |
241-1316
|
[1] |
LINK,19.05mm Pitch
|
CAS
LINK - connector, #60 (W/Spring clip)
|
| 9. |
241-1116
|
[1] |
LINK,Chain, 19.05mm Pitch
|
CAS
LINK - connector, #60 (Comes with mesh wrap kit only) Superseded by part number: 86595251
|
| 10. |
541857R92
|
[1] |
SPROCKET,15T
|
IH
- idler, 15 tooth
|
| 11. |
700116040
|
[1] |
SUPPORT
|
HFI
- sprocket
|
