凯斯零件查询(8465) - CASE IH AUTO ROUND BALER (1/91-12/97) (3-04) - PICKUP ASSEMBLY, WITH HEX SHAFT ONLY, SERIAL NUMBER CFH0077001 THROUGH CFH0077005 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
177 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
NLS
|
[7] |
NO LONGER SERVICED
|
BAS
1-1/2 X 14 GAUGE NRMB
|
| 2. |
700114174
|
[1] |
SPACER
|
CAS
|
| 3. |
700114148
|
[1] |
ROTOR
|
HFI
WA
|
| 4. |
413-616
|
[3] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 5. |
492-11038
|
[9] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 6. |
700709621
|
[2] |
SPHERICAL BEARING,31.78mm Hex x 72mm OD x 25mm W
|
CAS
BEARING Superseded by part number: 47442495
|
| 7. |
617863R1
|
[4] |
FLANGED BEARING
|
IH
- bearing
|
| 8. |
413-620
|
[3] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
C Hex, 3/8"-16 x 1 1/4", G5, Full Thd Superseded by part number: 72187207, 88011
|
| 9. |
425-106
|
[6] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 10. |
434-616
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 11. |
395871
|
[1] |
SPACER
|
CAS
|
| 12. |
20767R1
|
[1] |
PIN,3/8" x 2 1/4", Coiled
|
IH
3/8" x 2 1/4", Coiled Superseded by part number: 87610718
|
| 13. |
700117122
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET 50B35 TOOTH
|
| 14. |
52712
|
[1] |
BUSHING
|
CAS
1-1/2 X 18 GAUGE NRMB
|
